McIntosh MC462 User Manual

18
Specications
Specications
Power Output
Minimum sine wave continuous average power output
per channel, with both channels operating is:
450 watts into 2 ohm load
450 watts into 4 ohm load
450 watts into 8 ohm load
Output Load Impedance
2, 4 or 8 ohms
Rated Power Band
20Hz to 20,000Hz
Total Harmonic Distortion
0.005% maximum harmonic distortion at any power
level from 250 milliwatts to rated power, 20Hz to
20,000Hz
Dynamic Headroom
3.0dB
Frequency Response
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 100,000Hz
Input Sensitivity (for rated output)
4.2 Volts Balanced
2.1 Volts Unbalanced
Signal To Noise Ratio (A-Weighted)
95dB Balanced (122dB below rated output)
93dB Unbalanced (120dB below rated output)
Intermodulation Distortion
0.005% maximum, if the instantaneous peak power
output does not exceed twice the rated power output
for any combination of frequencies from 20Hz to
20,000Hz.
Wide Band Damping Factor
Greater than 40
Input Impedance
22,000 ohms Balanced
22,000 ohms Unbalanced
Volt a ge Gain
29dB, 8 Ohms
26dB, 4 Ohms
23dB, 2 Ohms
Power Guard
Less than 2% Total Harmonic Distortion with up to a
14dB overdrive signal
Power Control Input
5-15VDC, less than 1mA
Power Control Output 1 and 2
12VDC, 50mA maximum total
Output is delayed 0.2 seconds from turn On
Power Requirements
Field AC Voltage conversion of the MC462 is not
possible. The MC462 is factory configured for one of
the following AC Voltages:
100V ~ 50/60Hz at 12 Amps
110V ~ 50/60Hz at 11 Amps
120V ~ 50/60Hz at 10 Amps
127V ~ 50/60Hz at 10 Amps
220V ~ 50/60Hz at 6 Amps
230V ~ 50/60Hz at 6 Amps
240V ~ 50/60Hz at 6 Amps
Standby: less than 0.5 watt
Note: Refer to the rear panel of the MC462 for the cor-
rect voltage.
Overall Dimensions
Width is 17-1/2 inches (44.5cm)
Height is 9-7/16 inches (24cm) including feet
Depth is 22-1/2 inches (57.2cm) including the Front
Panel, Handles and Cables
Weight
115 pounds (52.3 kg) net, 148 pounds (67.3 kg) in ship-
ping carton
Shipping Carton Dimensions
Width is 29-1/2 inches (74.93cm)
Depth is 29 inches (73.66cm)
Height is 17 inches (43.18cm)

McIntosh MC462 Specifications

General

Power Output per Channel	450 Watts
Number of Channels	2
Total Harmonic Distortion	0.005%
Frequency Response	20Hz - 20kHz (+0, -0.25dB)
Dynamic Headroom	1.8dB
Damping Factor	>40
Rated Power Band	20Hz - 20kHz
Frequency Response Extended	10Hz - 100kHz (+0, -3dB)
Remote Power Control	Yes
Multi-Channel DB25 Cable	No
Output Impedance	2, 4, 8 Ohms
Dimensions	17.5 x 10.5 x 22 inches (W x H x D)
