9
How to Connect the MC602
To AC Outlet
Right
Loudspeaker
4 ohm
Left
Loudspeaker
4 ohm
Caution: The Loudspeaker Negative Connections are above chassis ground and are not
common between channels. Do not combine any connections together or ground them.
McIntosh C200C Controller McIntosh C200P Preamplifier
