McIntosh MC7106 User Manual

14. OUTPUTS 3 and 4, and BRIDGED OUTPUT
For separate channel operation, connect the Hot lead of a loudspeaker to the + (Plus)
RED upper terminal, and the Common lead to the - (Minus) BLACK lower terminal of each
channel.
For BRIDGED operation, connect the Hot lead of a loudspeaker to the + (Plus) RED upper
Channel 3, BRIDGED terminal, and the Common lead to the - Minus) RED upper Channel
4, BRIDGED terminal.
15. POWER CONTROL, IN/OUT
The MC7106 AC power can be turned on and off by a control signal fed to the POWER
CONTROL IN connector. This signal is available from a Mclntosh C39 or MX130 Control Center
through the 25 conductor computer type cable, or directly from a Control Center POWER CON-
TROL Output. The MC7106 POWER CONTROL OUT jack will feed the same AC power con-
trol signal out to another accessory component with a compatible Power Control input- The
POWER CONTROL connectors are standard 1/8 inch mini phone plugs. Only the tip and sleeve
are used for connections.
The MC7106 POWER switch must be in the OFF/REMOTE setting for the power control
signals to properly operate the MC7106 AC power.
16. OUTPUTS 5 and 6, and BRIDGED OUTPUT
For separate channel operation, connect the Hot lead of a loudspeaker to the + (Plus)
RED upper terminal, and the Common lead to the - (Minus) BLACK lower terminal of each
channel.
For BRIDGED operation, connect the Hot lead of a loudspeaker to the + (Plus) RED upper
Channel 5, BRIDGED terminal, and the Common lead to the - (Minus) RED upper Channel
6, BRIDGED terminal.
17. AC POWER CORD
Connect the MC7106 to a live 50/60Hz, 120 volt AC wall outlet. Do not connect the unit
to an AC outlet on the rear panel of a Preamplifier or Control Center.
18. 15A 250V (Fuse)
CAUTION: For continued protection against fire hazard, replace only with the same type
15A-250V SLO BLO fuse.
REAR PANEL
FEATURES
AND
CONNECTIONS
The following hookup diagrams show how to connect the six channels of the MC7106 in
four different output configurations. The MC7106 has excellent channel separation, so the
six channels can be used as six separate amplifiers, in mono or stereo, each with its dedicated
input signal and speaker output. Any of the following operating configurations can be used
for multi zone amplifier requirements.
AMPLIFIER/
SPEAKER
CONFIGURATIONS
9
