McIntosh MCC406M

5
Dimensions
The following dimensions can assist in determining the
best location for your MCC406M. There is additional in-
formation on the next page pertaining to installing the
MCC406M into your vehicle.
Dimensions
18-3/8"
46.66cm
Top View of the MCC406M
Side View of the MCC406M
3-3/16"
8.09cm
9-3/16"
23.33cm
15-3/16"
38.57cm
11-13/16"
29.97cm
12-1/4"
31.12cm
2-15/16"
7.49cm
11"
27.93cm
11/32"
10.93cm
