McIntosh MP1100 - Page 40

66
Ref. No. Description Part No.
LEFT AUDIO PCB 751910 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
3
R165 RES SMD0805 4.75K 1/8W 1% 145008
R166 RES SMD0805 221K 1/8W 1% 145038
R167 RES TF 200 .5% 0.125W SMD0805 145124
R168 RES TF 200 .5% 0.125W SMD0805 145124
R169 RES TF 200 .5% 0.125W SMD0805 145124
R170 RES TF 10K 1% 0.1W SMD0805 145061
R171 RES TF 10K 1% 0.1W SMD0805 145061
R172 RES TF 10K 1% 0.1W SMD0805 145061
R173 RES SMD0805 221K 1/8W 1% 145038
R174 RES TF 402 .5% 0.125W SMD0805 145125
R175 RES TF 402 .5% 0.125W SMD0805 145125
R176 RES TF 402 .5% 0.125W SMD0805 145125
R177 RES SMD0805 22.1K 1/8W 1% 145012
R178 RES SMD0805 22.1K 1/8W 1% 145012
R179 RES SMD0805 22.1K 1/8W 1% 145012
R180 RES SMD0805 221K 1/8W 1% 145038
R181 RES TF 1K 1% 0.1W SMD0805 145117
R182 RES TF 1K 1% 0.1W SMD0805 145117
R183 RES TF 1K 1% 0.1W SMD0805 145117
R184 RES SMD0805 22.1K 1/8W 1% 145012
R185 RES SMD0805 22.1K 1/8W 1% 145012
R186 RES SMD0805 22.1K 1/8W 1% 145012
R187 RES SMD0805 221K 1/8W 1% 145038
R188 RES TF 47.5K 1% 0.125W SMD0805 145132
R189 RES TF 47.5K 1% 0.125W SMD0805 145132
R190 RES TF 47.5K 1% 0.125W SMD0805 145132
R191 RES SMD0805 221K 1/8W 1% 145038
R192 RES TF 47.5K 1% 0.125W SMD0805 145132
R193 RES TF 47.5K 1% 0.125W SMD0805 145132
R194 RES TF 47.5K 1% 0.125W SMD0805 145132
R195 RES SMD0805 221K 1/8W 1% 145038
R196 RES TF 47.5K 1% 0.125W SMD0805 145132
R197 RES TF 47.5K 1% 0.125W SMD0805 145132
R198 RES TF 47.5K 1% 0.125W SMD0805 145132
R199 RES SMD0805 221K 1/8W 1% 145038
R200 RES TF 47.5K 1% 0.125W SMD0805 145132
R201 RES TF 47.5K 1% 0.125W SMD0805 145132
R202 RES TF 47.5K 1% 0.125W SMD0805 145132
R203 RES SMD0805 4.75K 1/8W 1% 145008
R204 RES SMD0805 4.75K 1/8W 1% 145008
R205 RES SMD0805 4.75K 1/8W 1% 145008
R206 RES SMD0805 4.75K 1/8W 1% 145008
R207 RES SMD0805 4.75K 1/8W 1% 145008
R208 RES SMD0805 4.75K 1/8W 1% 145008
R209 RES SMD0805 4.75K 1/8W 1% 145008
R210 RES TF 22.1 5% 0.1W SMD0805 145133
R211 RES TF 22.1 5% 0.1W SMD0805 145133
R212 RES TF 22.1 5% 0.1W SMD0805 145133
R213 RES TF 22.1 5% 0.1W SMD0805 145133
R214 RES TF 22.1 5% 0.1W SMD0805 145133
R215 RES TF 22.1 5% 0.1W SMD0805 145133
R216 RES SMD0805 4.75K 1/8W 1% 145008
R217 RES TF 750 1% 0.125W SMD0805 145139
R218 RES TF 750 1% 0.125W SMD0805 145139
R219 RES TF 750 1% 0.125W SMD0805 145139
R220 RES TF 47.5K 1% 0.125W SMD0805 145132
R221 RES TF 750 1% 0.125W SMD0805 145139
R222 RES TF 47.5K 1% 0.125W SMD0805 145132
R223 RES TF 47.5K 1% 0.125W SMD0805 145132
TUBE PCB 751913
4
R224 RES TF 750 1% 0.125W SMD0805 145139
R225 RES TF 750 1% 0.125W SMD0805 145139
R226 RES TF 2K 1% 0.1W SMD0805 145115
R227 RES TF 2K 1% 0.1W SMD0805 145115
R228 RES TF 2K 1% 0.1W SMD0805 145115
R229 RES TF 2K 1% 0.1W SMD0805 145115
R230 RES TF 2K 1% 0.1W SMD0805 145115
R231 RES TF 2K 1% 0.1W SMD0805 145115
R232 RES SMD0805 22.1K 1/8W 1% 145012
R233 RES SMD0805 22.1K 1/8W 1% 145012
R234 RES TF 10K 1% 0.1W SMD0805 145061
R235 RES SMD0805 4.75K 1/8W 1% 145008
R236 RES SMD0805 4.75K 1/8W 1% 145008
R237 RES SMD0805 4.75K 1/8W 1% 145008
R238 RES SMD0805 4.75K 1/8W 1% 145008
R239 RES SMD0805 4.75K 1/8W 1% 145008
R240 RES SMD0805 221K 1/8W 1% 145038
R241 RES TF 750 1% 0.125W SMD0805 145139
R242 RES TF 3.83K 1% 0.1W SMD0805 145083
R243 RES TF 3.83K 1% 0.1W SMD0805 145083
R244 RES TF 47.5K 1% 0.125W SMD0805 145132
R245 RES SMD0805 221K 1/8W 1% 145038
R246 RES SMD0805 221K 1/8W 1% 145038
R247 RES TF 10 1% 0.1W SMD0805 145063
R248 RES TF 10 1% 0.1W SMD0805 145063
R249 RES TF 10 1% 0.1W SMD0805 145063
R250 RES TF 2K 1% 0.1W SMD0805 145115
R251 RES TF 2K 1% 0.1W SMD0805 145115
R252 RES TF 2K 1% 0.1W SMD0805 145115
U1 IC 8 BIT I/O PORT SMD 133896
U2 IC 8 BIT DRIVER SMD 133461
U3 IC 8 BIT DRIVER SMD 133461
U4 IC 8 BIT DRIVER SMD 133461
U5 IC DUAL OP AMP 5532 SMD 133718
U6 IC DUAL OP AMP 5532 SMD 133718
U7 REG POS ADJ 1.5A SMD 133822
U8 IC OP DUAL AMP 33178 SMD 133720
U9 REG REG NEG ADJ 1.5A SMD 133821
U10 IC OP DUAL AMP 33178 SMD 133720
U11 IC OP AMP DIFFERENTIAL SMD 133881
U13 IC DUAL OP AMP 5532 SMD 133718
U15 IC DUAL OP AMP 5532 SMD 133718
U16 IC DUAL OP AMP 5532 SMD 133718
U17 IC DUAL OP AMP 5532 SMD 133718
U18 IC DUAL OP AMP 5532 SMD 133718
U12 IC OP AMP 5534 LOW NOISE SMD 133719
U14 IC DUAL JFET OP AMP SMD 133778
C1 CAP MPF 0.01UF 5% 250V 064472
C2 CAP POLYPROP 0.22UF 400V 20% 064438
C3 CAP .47uF 50V 20% X7R SMD0805 061373
C4 CAP NPO 1000pF 100V 5% SMD0805 061391
C5 CAP 47pF 200V 10% NPO SMD0805 061368
C7 CAP ELECT 100UF 25V SMD 066605
C8 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C9 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C10 CAP ELECT 100UF 25V SMD 066605
C11 CAP 10uF 20% 16V X5R SMD0805 061392
