MP1100
67
Ref. No. Description Part No.
TUBE PCB 751913 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
4
C12 CAP 47pF 200V 10% NPO SMD0805 061368
C13 CAP NPO 1000pF 100V 5% SMD0805 061391
C14 CAP ELECT 100UF 25V SMD 066605
C15 CAP MPF 0.01UF 5% 250V 064472
C16 CAP POLYPROP 0.22UF 400V 20% 064438
C17 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C18 CAP MPF 0.01UF 5% 250V 064472
C19 CAP POLYPROP 0.22UF 400V 20% 064438
C20 CAP NPO 1000pF 100V 5% SMD0805 061391
C21 CAP .47uF 50V 20% X7R SMD0805 061373
C22 CAP 47pF 200V 10% NPO SMD0805 061368
C24 CAP ELECT 100UF 25V SMD 066605
C25 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C26 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C27 CAP ELECT 100UF 25V SMD 066605
C28 CAP 10uF 20% 16V X5R SMD0805 061392
C29 CAP 47pF 200V 10% NPO SMD0805 061368
C30 CAP NPO 1000pF 100V 5% SMD0805 061391
C31 CAP ELECT 100UF 25V SMD 066605
C32 CAP MPF 0.01UF 5% 250V 064472
C33 CAP POLYPROP 0.22UF 400V 20% 064438
C34 CAP MONO .1uF 50V +/-20% X7R SMD 061365
D1 DIODE SMALL SIGNAL 4148 SMD 070199
D2 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SMALL SIGNAL 4148 SMD 070199
D4 DIODE SMALL SIGNAL 4148 SMD 070199
D5 DIODE SMALL SIGNAL 4148 SMD 070199
D6 DIODE SMALL SIGNAL 4148 SMD 070199
D7 DIODE SMALL SIGNAL 4148 SMD 070199
D8 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 LED RGB SMD 058209
DS2 LED RGB SMD 058209
DS3 LED RGB SMD 058209
DS4 LED RGB SMD 058209
J1 CONN 12 PIN FFC 117907
J2 CONN 8 PIN 2.5MM SHROUDED 118046
J3 CONN 12 PIN FFC 117907
J4 CONN 8 PIN 2.5MM SHROUDED 118046
PCB1 PC BD TUBE 130337
Q1 TRANSISTOR NPN A05 SMD 132333
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
Q4 TRANSISTOR NPN A05 SMD 132333
R1 RES TF 221K .125W .5% SMD0805 145140
R2 RES TF 221K .125W .5% SMD0805 145140
R3 RES SMD0805 475K 1/8W 1% 145040
R4 RES TF 2K 1% 0.1W SMD0805 145115
R5 RES TF 1M 1% 0.125W SMD0805 145131
R6 RES TF 221K .125W .5% SMD0805 145140
R7 RES TF 1K 1% 0.1W SMD0805 145117
R8 RES TF 2K 1% 0.1W SMD0805 145115
R9 RES TF 1K 1% 0.1W SMD0805 145117
R10 RES TF 2K 1% 0.1W SMD0805 145115
R11 RES TF 1K 1% 0.1W SMD0805 145117
R12 RES SMD0805 6.81K 1/8W 1% 145029
R13 RES SMD0805 4.75K 1/8W 1% 145008
R14 RES SMD0805 4.75K 1/8W 1% 145008
R15 RES SMD0805 4.75K 1/8W 1% 145008
R16 RES SMD0805 681 1/8W 1% 145002
R17 RES SMD0805 15K 1/8W 1% 145011
R18 RES TF 2K 1% 0.1W SMD0805 145115
R19 RES TF 1M 1% 0.125W SMD0805 145131
R20 RES SMD0805 475K 1/8W 1% 145040
R21 RES TF 221K .125W .5% SMD0805 145140
R22 RES TF 221K .125W .5% SMD0805 145140
R23 RES SMD0805 6.81K 1/8W 1% 145029
R24 RES SMD0805 47.5K 1/8W 1% 145013
R25 RES SMD0805 10K 1/8W 1% 145010
R26 RES TF 221K .125W .5% SMD0805 145140
R27 RES TF 221K .125W .5% SMD0805 145140
R28 RES SMD0805 475K 1/8W 1% 145040
R29 RES TF 2K 1% 0.1W SMD0805 145115
R30 RES TF 1M 1% 0.125W SMD0805 145131
R31 RES TF 221K .125W .5% SMD0805 145140
R32 RES TF 1K 1% 0.1W SMD0805 145117
R33 RES TF 2K 1% 0.1W SMD0805 145115
R34 RES TF 1K 1% 0.1W SMD0805 145117
R35 RES TF 2K 1% 0.1W SMD0805 145115
R36 RES TF 1K 1% 0.1W SMD0805 145117
R37 RES SMD0805 4.75K 1/8W 1% 145008
R38 RES SMD0805 6.81K 1/8W 1% 145029
R39 RES SMD0805 4.75K 1/8W 1% 145008
R40 RES SMD0805 4.75K 1/8W 1% 145008
R41 RES SMD0805 681 1/8W 1% 145002
R42 RES SMD0805 15K 1/8W 1% 145011
R43 RES TF 2K 1% 0.1W SMD0805 145115
R44 RES TF 1M 1% 0.125W SMD0805 145131
R45 RES SMD0805 475K 1/8W 1% 145040
R46 RES TF 221K .125W .5% SMD0805 145140
R47 RES TF 221K .125W .5% SMD0805 145140
R48 RES SMD0805 6.81K 1/8W 1% 145029
R49 RES SMD0805 47.5K 1/8W 1% 145013
R50 RES SMD0805 10K 1/8W 1% 145010
U1 IC DUAL JFET OP AMP SMD 133778
U2 IC DUAL JFET OP AMP SMD 133778
V1 SOCKET TUBE 9 PIN GOLD PLATED 178195
V2 SOCKET TUBE 9 PIN GOLD PLATED 178195
V3 SOCKET TUBE 9 PIN GOLD PLATED 178195
V4 SOCKET TUBE 9 PIN GOLD PLATED 178195
DIGITAL PCB 752027
5
C1 CAP ELECT 1000UF 25V 066513
C2 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C3 CAP ELECT 3300UF 35V 066509
C4 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C5 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C6 CAP ELECT 220UF 25V SMD 066606
C7 CAP .01uF 50V 20% X7R SMD0805 061372
C8 CAP NPO 1000pF 100V 5% SMD0805 061391
C9 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C10 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C11 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C12 CAP 3300PF 250V UL/CSA 061312
C13 CAP ELECT 10000UF 10V 066595
C14 CAP ELECT 22UF 450V 066630
C15 CAP ELECT 10000UF 10V 066595
C16 CAP ELECT 10000UF 10V 066595
C17 CAP POLYPROP 0.22UF 400V 20% 064438
