McIntosh MP1100 - Page 42

68
Ref. No. Description Part No.
DIGITAL PCB 752027 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
C18 CAP ELECT 3300UF 35V 066509
C19 CAP ELECT 3300UF 35V 066509
C20 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C22 CAP ELECT 3300UF 35V 066509
C23 CAP ELECT 3300UF 35V 066509
C24 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C25 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C26 CAP .01uF 50V 20% X7R SMD0805 061372
C27 CAP .01uF 50V 20% X7R SMD0805 061372
C28 CAP ELECT 220UF 25V SMD 066606
C29 CAP ELECT 220UF 25V SMD 066606
C30 CAP ELECT 220UF 25V SMD 066606
C31 CAP ELECT 220UF 25V SMD 066606
C32 CAP ELECT 220UF 25V SMD 066606
C33 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C34 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C35 CAP .01uF 50V 20% X7R SMD0805 061372
C36 CAP .01uF 50V 20% X7R SMD0805 061372
C37 CAP ELECT 220UF 25V SMD 066606
C38 CAP ELECT 220UF 25V SMD 066606
C39 CAP 10uF 20% 16V X5R SMD0805 061392
C40 CAP 10uF 20% 16V X5R SMD0805 061392
C41 CAP 10uF 20% 16V X5R SMD0805 061392
C42 CAP 10uF 20% 16V X5R SMD0805 061392
C43 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C44 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C47 CAP ELECT 220UF 25V SMD 066606
C48 CAP ELECT 220UF 25V SMD 066606
C49 CAP ELECT 220UF 25V SMD 066606
C50 CAP ELECT 220UF 25V SMD 066606
C51 CAP 10uF 20% 16V X5R SMD0805 061392
C52 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C53 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C54 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C55 CAP 10uF 20% 16V X5R SMD0805 061392
C56 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C57 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C58 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C59 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C60 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C61 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C62 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C63 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C64 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C65 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C66 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C67 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C68 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C69 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C70 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C71 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C72 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C73 CAP NPO 1000pF 100V 5% SMD0805 061391
C74 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C75 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C76 CAP .01uF 50V 20% X7R SMD0805 061372
C77 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C78 CAP ELECT 220UF 25V SMD 066606
C79 CAP ELECT 100UF 25V SMD 066605
C80 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C81 CAP 10uF 20% 16V X5R SMD0805 061392
C82 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C83 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C84 CAP ELECT 100UF 25V SMD 066605
C85 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C86 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C87 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C88 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C89 CAP 10uF 20% 16V X5R SMD0805 061392
C90 CAP 10uF 20% 16V X5R SMD0805 061392
C91 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C92 CAP 10uF 20% 16V X5R SMD0805 061392
C93 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C94 CAP .01uF 50V 20% X7R SMD0805 061372
C95 CAP ELECT 220UF 25V SMD 066606
C96 CAP .01uF PPS 50V 2% SMD1206 064473
C97 CAP .01uF PPS 50V 2% SMD1206 064473
C98 CAP 10uF 20% 16V X5R SMD0805 061392
C99 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C100 CAP 10uF 20% 16V X5R SMD0805 061392
C101 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C102 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C103 CAP 10uF 20% 16V X5R SMD0805 061392
C104 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C105 CAP ELECT 100UF 25V SMD 066605
C106 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C107 CAP .01uF PPS 50V 2% SMD1206 064473
C108 CAP .01uF PPS 50V 2% SMD1206 064473
C109 CAP 10uF 20% 16V X5R SMD0805 061392
C110 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C111 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C112 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C113 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C114 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C115 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C118 CAP ELECT 10UF 250V 066558
C119 CAP ELECT 10UF 250V 066558
C120 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C121 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C122 CAP MONO .1uF 50V +/- 20% X7R SMD 061365
C123 CAP NPO 1000pF 100V 5% SMD0805 061391
C124 CAP NPO 1000pF 100V 5% SMD0805 061391
C125 CAP NPO 1000pF 100V 5% SMD0805 061391
C126 CAP NPO 1000pF 100V 5% SMD0805 061391
C127 CAP 10uF 20% 16V X5R SMD0805 061392
C128 CAP 10uF 20% 16V X5R SMD0805 061392
C129 CAP 10uF 20% 16V X5R SMD0805 061392
D1 DIODE SCHOTTKY 40V 2A SMD 070210
D2 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SCHOTTKY 40V 2A SMD 070210
D4 DIODE SCHOTTKY 40V 2A SMD 070210
D5 DIODE SCHOTTKY 40V 2A SMD 070210
D6 DIODE SCHOTTKY 40V 2A SMD 070210
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE SMALL SIGNAL 4148 SMD 070199
D10 DIODE ESD SUPPRESSOR SMD 070198
D11 DIODE SMALL SIGNAL 4148 SMD 070199
