MP1100
69
Ref. No. Description Part No.
DIGITAL PCB 752027 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
D12 DIODE RECTIFIER 1000V 1A SMD 070225
D13 DIODE RECTIFIER 1000V 1A SMD 070225
D14 DIODE RECTIFIER 100V 1.7A SMD 070229
D15 DIODE RECTIFIER 100V 1.7A SMD 070229
D16 DIODE RECTIFIER 100V 1.7A SMD 070229
D17 DIODE RECTIFIER 100V 1.7A SMD 070229
D18 DIODE SCHOTTKY 40V 2A SMD 070210
D19 DIODE SCHOTTKY 40V 2A SMD 070210
D20 DIODE SCHOTTKY 40V 2A SMD 070210
D21 DIODE SCHOTTKY 40V 2A SMD 070210
D22 DIODE RECTIFIER 1000V 1A SMD 070225
D23 DIODE RECTIFIER 1000V 1A SMD 070225
D24 DIODE ZENER 10V 5% 0.35W SMD 070222
D25 DIODE ESD SUPPRESSOR SMD 070198
D26 DIODE ESD SUPPRESSOR SMD 070198
D27 DIODE ESD SUPPRESSOR SMD 070198
DS1 LED RGB SMD 058209
FH1 HOLDER FUSE 5X20 PCB MOUNT 178159
FH2 HOLDER FUSE 5X20 PCB MOUNT 178159
GP1 TERMINAL PC MOUNT 4-40 118115
GP2 TERMINAL PC MOUNT 4-40 118115
GP3 TERMINAL PC MOUNT 4-40 118115
GP5 TERMINAL PC MOUNT 4-40 118115
J1 CONNECTOR 2 PIN HEADER 11.88MM 118026
J2 CONN PCB MOUNT POWER RED 117719
J3 CONN 2 PIN MALE 117213
J4 CONN PCB MOUNT POWER RED 117719
J5 JACK HEADPHONE DUAL BLACK 1/8” 117825
J6 JACK HEADPHONE STEREO 1/8IN 117945
J7 HEADER 9 CIRCUIT POST NATURAL 117724
J8 CONN 8 PIN 2.5MM SHROUDED 118046
J9 CONN 8 PIN 2.5MM SHROUDED 118046
J10 CONN 23 PIN FFC SMD 118004
J11 CONN SHROUDED HEADER 2 X 8 117977
J12 CONN 18 PIN FFC SMD 118003
J13 CONN 18 PIN FFC SMD 118003
J14 CONN USB JACK TYPE B RT ANGLE 117905
J15 JACK SINGLE RCA 118135
K1 RELAY 12VDC 5A 250VAC TV-4 087077
F1 FUSE 1/8A SLO-BLO 5x20 IEC 089128
L1 FERRITE 1500 OHMS 1A SMD 122464
L2 FERRITE 1500 OHMS 1A SMD 122464
L3 FERRITE 1500 OHMS 1A SMD 122464
L4 FERRITE 1500 OHMS 1A SMD 122464
L5 FERRITE 1500 OHMS 1A SMD 122464
L6 FERRITE 1500 OHMS 1A SMD 122464
L7 COMMON MODE CHOKE 90 OHM SMD 122454
L8 FERRITE 1500 OHMS 1A SMD 122464
L9 FERRITE 1500 OHMS 1A SMD 122464
L10 FERRITE 1500 OHMS 1A SMD 122464
L11 INDUCTOR 100UH 20% SMD 122440
L12 FERRITE 1500 OHMS 1A SMD 122464
L13 FERRITE 1500 OHMS 1A SMD 122464
L14 FERRITE 1500 OHMS 1A SMD 122464
L15 FERRITE 1500 OHMS 1A SMD 122464
L16 FERRITE 1500 OHMS 1A SMD 122464
L17 FERRITE 1500 OHMS 1A SMD 122464
L18 FERRITE 1500 OHMS 1A SMD 122464
L19 FERRITE 1500 OHMS 1A SMD 122464
L20 FERRITE 1500 OHMS 1A SMD 122464
L21 FERRITE 1500 OHMS 1A SMD 122464
L22 FERRITE 1500 OHMS 1A SMD 122464
L23 FERRITE 1500 OHMS 1A SMD 122464
L24 FERRITE 1500 OHMS 1A SMD 122464
L25 FERRITE 1500 OHMS 1A SMD 122464
L26 FERRITE 1500 OHMS 1A SMD 122464
L27 FERRITE 1500 OHMS 1A SMD 122464
L28 FERRITE 1500 OHMS 1A SMD 122464
L29 FERRITE 1500 OHMS 1A SMD 122464
L30 FERRITE 1500 OHMS 1A SMD 122464
L31 FERRITE 1500 OHMS 1A SMD 122464
L32 FERRITE 1500 OHMS 1A SMD 122464
L33 FERRITE 1500 OHMS 1A SMD 122464
L34 FERRITE 1500 OHMS 1A SMD 122464
L35 FERRITE 1500 OHMS 1A SMD 122464
L36 FERRITE 1500 OHMS 1A SMD 122464
L37 FERRITE 1500 OHMS 1A SMD 122464
OPT1 FIBER OPTIC TRANSMITTER 3-5V 058214
PCB1 PC BD DIGITAL 130382
Q1 TRANSISTOR NPN A05 SMD 132333
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
Q4 TRANSISTOR NCH MOSFET 800V SMD 132353
Q5 TRANSISTOR NPN A05 SMD 132333
Q6 TRANSISTOR NPN 300V BF420 132351
Q7 TRANSISTOR NPN A05 SMD 132333
Q8 TRANSISTOR NPN A05 SMD 132333
Q9 TRANSISTOR PNP A55 SMD 132334
Q10 TRANSISTOR PNP A55 SMD 132334
Q11 TRANSISTOR NPN A05 SMD 132333
Q12 TRANSISTOR NPN A05 SMD 132333
Q13 TRANSISTOR NPN A05 SMD 132333
Q14 TRANSISTOR NPN A05 SMD 132333
Q15 TRANSISTOR NPN A05 SMD 132333
Q16 TRANSISTOR NPN A05 SMD 132333
R1 RES SMD0805 2.21K 1/8W 1% 145024
R2 FUSE 0.35A 16V RESET 1206 SMD 145054
R3 FUSE 0.35A 16V RESET 1206 SMD 145054
R4 RES SMD0805 10 1/8W 1% 145017
R5 RES SMD0805 47.5K 1/8W 1% 145013
R6 RES SMD0805 1.5K 1/8W 1% 145022
R7 RES SMD0805 47.5K 1/8W 1% 145013
R8 RES SMD0805 150K 1/8W 1% 145037
R9 RES SMD0805 22.1K 1/8W 1% 145012
R10 RES SMD0805 22.1K 1/8W 1% 145012
R11 RES SMD0805 47.5K 1/8W 1% 145013
R12 RES SMD0805 22.1K 1/8W 1% 145012
R13 RES SMD0805 47.5K 1/8W 1% 145013
R14 RES SMD0805 47.5K 1/8W 1% 145013
R15 POLYSWITCH 1.85A 72V 144716
R16 POLYSWITCH 1.85A 72V 144716
R17 POLYSWITCH 3.00A 72V 144722
R18 POLYSWITCH 3.00A 72V 144722
R19 RES SMD0805 221K 1/8W 1% 145038
R20 RES SMD0805 221K 1/8W 1% 145038
R21 RES TF 49.9K 1% 0.1W SMD0805 145085
R22 RES TF 49.9K 1% 0.1W SMD0805 145085
R23 RES SMD0805 1M 1/8W 1% 145042
To Next Page
