McIntosh MP1100 - Page 44

70
Ref. No. Description Part No.
DIGITAL PCB 752027 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
R24 RES SMD0805 1.5K 1/8W 1% 145022
R25 RES SMD0805 475 1/8W 1% 145020
R26 RES SMD0805 4.75K 1/8W 1% 145008
R27 RES SMD0805 475 1/8W 1% 145020
R28 RES SMD0805 4.75K 1/8W 1% 145008
R29 RES SMD0805 221K 1/8W 1% 145038
R30 RES SMD0805 221K 1/8W 1% 145038
R31 RES TF 47.5 1% .125W SMD0805 145128
R32 RES SMD0805 2.21K 1/8W 1% 145024
R33 RES SMD0805 221K 1/8W 1% 145038
R34 RES TF 75K 1% 0.125W SMD0805 145130
R35 RES TF 75K 1% 0.125W SMD0805 145130
R36 RES TF 20.0K 0.1% 0.1W SMD0805 145072
R37 RES SMD0805 1K 1/8W 1% 145007
R38 RES SMD0805 1K 1/8W 1% 145007
R39 RES TF 49.9K 1% 0.1W SMD0805 145085
R40 RES TF 49.9K 1% 0.1W SMD0805 145085
R41 RES SMD0805 150K 1/8W 1% 145037
R42 RES SMD0805 150K 1/8W 1% 145037
R43 RES SMD0805 475 1/8W 1% 145020
R44 RES SMD0805 475 1/8W 1% 145020
R45 RES SMD0805 475 1/8W 1% 145020
R46 RES SMD0805 475 1/8W 1% 145020
R47 RES SMD0805 1.21K 1/8W 1% 145021
R48 RES SMD0805 1.21K 1/8W 1% 145021
R49 RES SMD0805 1.21K 1/8W 1% 145021
R50 RES SMD0805 1.21K 1/8W 1% 145021
R51 RES SMD0805 4.75K 1/8W 1% 145008
R52 RES SMD0805 4.75K 1/8W 1% 145008
R53 RES SMD0805 4.75K 1/8W 1% 145008
R54 RES SMD0805 4.75K 1/8W 1% 145008
R55 RES SMD0805 10K 1/8W 1% 145010
R56 RES SMD0805 10K 1/8W 1% 145010
R57 RES SMD0805 10 1/8W 1% 145017
R58 RES SMD0805 2.21K 1/8W 1% 145024
R59 RES SMD0805 22.1 1/8W 1% 145003
R60 RES SMD0805 22.1 1/8W 1% 145003
R61 RES SMD0805 1K 1/8W 1% 145007
R62 RES SMD0805 47.5K 1/8W 1% 145013
R63 RES SMD0805 4.75K 1/8W 1% 145008
R64 RES SMD0805 4.75K 1/8W 1% 145008
R65 RES SMD0805 10K 1/8W 1% 145010
R66 RES SMD0805 4.75K 1/8W 1% 145008
R67 RES SMD0805 4.75K 1/8W 1% 145008
R68 RES SMD0805 OPEN NONE
R69 RES SMD0805 4.75K 1/8W 1% 145008
R70 RES SMD0805 4.75K 1/8W 1% 145008
R71 RES SMD0805 4.75K 1/8W 1% 145008
R72 RES SMD0805 4.75K 1/8W 1% 145008
R73 RES SMD0805 4.75K 1/8W 1% 145008
R74 RES SMD0805 4.75K 1/8W 1% 145008
R75 RES SMD0805 4.75K 1/8W 1% 145008
R76 RES SMD0805 100 1/8W 1% 145005
R77 RES SMD0805 47.5 1/8W 1% 145004
R78 RES SMD0805 47.5 1/8W 1% 145004
R79 RES SMD0805 33.2K 1/8W 1% 145033
R80 RES SMD0805 56.2K 1/8W 1% 145034
R81 RES SMD0805 47.5K 1/8W 1% 145013
R82 RES SMD0805 10K 1/8W 1% 145010
R83 RES SMD0805 22.1 1/8W 1% 145003
R84 RES SMD0805 22.1 1/8W 1% 145003
R85 RES SMD0805 10K 1/8W 1% 145010
R86 RES SMD0805 10K 1/8W 1% 145010
R87 RES SMD0805 10K 1/8W 1% 145010
R88 RES SMD0805 10K 1/8W 1% 145010
R89 RES SMD0805 10K 1/8W 1% 145010
R90 RES SMD0805 10K 1/8W 1% 145010
R91 RES SMD0805 100 1/8W 1% 145005
R92 RES SMD0805 100 1/8W 1% 145005
R93 RES SMD0805 10K 1/8W 1% 145010
R94 RES SMD0805 10K 1/8W 1% 145010
R95 RES SMD0805 10K 1/8W 1% 145010
R96 RES SMD0805 270 1/8W 1% 145116
R97 RES SMD0805 10K 1/8W 1% 145010
R98 RES SMD0805 10K 1/8W 1% 145010
R99 RES SMD0805 10K 1/8W 1% 145010
R100 RES TF 49.9K 1% 0.1W SMD0805 145085
R101 RES SMD0805 33.2K 1/8W 1% 145033
R102 RES SMD0805 150K 1/8W 1% 145037
R103 RES SMD0805 OPEN NONE
R104 RES SMD0805 47.5 1/8W 1% 145004
R105 RES SMD0805 4.75K 1/8W 1% 145008
R106 RES SMD0805 4.75K 1/8W 1% 145008
R107 RES SMD0805 10 1/8W 1% 145017
R108 RES SMD0805 4.75K 1/8W 1% 145008
R109 RES SMD0805 4.75K 1/8W 1% 145008
R110 RES SMD0805 332 1/8W 1% 145006
R111 RES SMD0805 100 1/8W 1% 145005
R112 RES SMD0805 10K 1/8W 1% 145010
R113 RES SMD0805 10K 1/8W 1% 145010
R114 RES SMD0805 10K 1/8W 1% 145010
R115 RES SMD0805 10K 1/8W 1% 145010
R116 RES SMD0805 1.21K 1/8W 1% 145021
R117 RES SMD0805 1.21K 1/8W 1% 145021
R118 RES SMD0805 100K 1/8W 1% 145014
R119 RES SMD0805 47.5K 1/8W 1% 145013
R120 RES SMD0805 100K 1/8W 1% 145014
R121 RES SMD0805 100K 1/8W 1% 145014
R122 RES SMD0805 OPEN NONE
R123 RES SMD0805 47.5 1/8W 1% 145004
R124 RES TF 75K 1% 0.125W SMD0805 145130
R125 RES SMD0805 OPEN NONE
R126 RES SMD0805 4.75K 1/8W 1% 145008
R127 RES SMD0805 4.75K 1/8W 1% 145008
R128 RES SMD0805 100K 1/8W 1% 145014
S1 S2 SWITCH TACT 260GF 5MM SMD 150072
T1 TRANSFORMER BACKUP 159376
T2 TRANSFORMER DIGITAL INTERFACE 159351
U1 IC REGULATOR 3.3V 500mA SMD 133736
U2 IC OPTOCOUPLER SCHMITT SMD 133879
U3 IC SINGLE NAND SCHMITT SMD 133724
U4 IC SINGLE NAND SCHMITT SMD 133724
U5 IC SINGLE NAND SCHMITT SMD 133724
U6 IC MONO MULTIVIBRATOR SMD 133738
U7 IC SNGLE 2-INPUT NAND GATE SMD 133501
U8 IC ‘REG POS ADJ 1.5A SMD 133822
U9 REG NEG ADJ 1A WITH ENA SMD 133731
U10 IC ‘REG POS ADJ 1.5A SMD 133822
