McIntosh MP1100

MP1100
71
Ref. No. Description Part No.
DIGITAL PCB 752027 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
U11 REG NEG ADJ 1A WITH ENA SMD 133731
U12 IC REG 1.2A LO-DROP ENABLE SMD 133717
U13 IC REG 1.2A LO-DROP ENABLE SMD 133717
U14 IC ‘REG POS ADJ 1.5A SMD 133822
U15 IC REG NEG ADJ 1.5A SMD 133821
U16 IC ‘REG POS ADJ 1.5A SMD 133822
U17 IC REG NEG ADJ 1.5A SMD 133821
U18 IC SINGLE 2-INPUT AND GATE SMD 133552
U19 IC SINGLE 2-INPUT AND GATE SMD 133552
U20 IC SINGLE 2-INPUT AND GATE SMD 133552
U21 IC MICRO 32-BIT SAM4S SMD 133875
U22 IC SNGLE 2-INPUT NAND GATE SMD 133501
U23 IC I2C BUS REPEATER SMD 133769
U24 IC EEPROM 256K BITS 3.3V SMD 133709
U25 IC I2C BUS REPEATER SMD 133769
U26 IC 8 BIT I/O PORT SMD 133896
U27 IC 8 BIT I/O PORT SMD 133896
U28 IC SINGLE NAND SCHMITT SMD 133724
U29 IC SINGLE 2-INPUT AND GATE SMD 133552
U30 IC SNGLE 2-INPUT NAND GATE SMD 133501
U31 IC SNGLE 2-INPUT NAND GATE SMD 133501
U32 IC CLOCK GENERATOR SMD 133869
U33 IC REG 1.2A LO-DROP ENABLE SMD 133717
U34 IC USB 2:1 MUX SWITCH SMD 133754
U35 IC EEPROM 256K BITS 3.3V SMD 133709
U36 IC USB AUDIO STREAMING SMD 133884
U37 IC SINGLE 2-INPUT AND GATE SMD 133552
U38 IC REG 1.2A LO-DROP ENABLE SMD 133717
U39 IC ADC 2CH 32/768k SMD 133905
U40 IC DIG AUDIO TX 24/192K SMD 133904
U41 IC DUAL RS232 3V W/SHUTDWN SMD 133707
U42 IC SNGLE 2-INPUT NAND GATE SMD 133501
Y1 CRYSTAL 12.00MHZ SMD 180103
Y2 CRYSTAL 24MHZ SMD 180102
Y3 CRYSTAL OSCLTOR 24.5760MHZ SMD 180084
FIRMWARE V1.00 MP1100 230242
FIRMWARE USB V1.00 MP1100 230243
DSPLY/STBY PSHBTN/MUTE PSHBTN/L MTR/R MTR PCB 751912
6
C1 CAP ELECT 10UF 50V SMD 066602
C3 CAP ELECT 10UF 50V SMD 066602
C2 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C4 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C5 CAP ELECT 100UF 25V SMD 066605
C6 CAP MONO .1uF 50V +/-20% X7R SMD 061365
D1 DIODE SMALL SIGNAL 4148 SMD 070199
D2 DIODE ESD SUPPRESSOR SMD 070198
D3 DIODE ESD SUPPRESSOR SMD 070198
DS1 LED RED HIGH EFFICIENCY 5MM 058207
DS2 ASSY VFD W/ SPACERS CAP TAPE PT 751926
DS3 LED GRN REV MOUNT SMD 058212
DS4 LED GRN REV MOUNT SMD 058212
DS5 LED GRN REV MOUNT SMD 058212
DS6 LED GRN REV MOUNT SMD 058212
DS7 LED GRN REV MOUNT SMD 058212
DS8 LED GRN REV MOUNT SMD 058212
DS9 LED GRN REV MOUNT SMD 058212
DS10 LED GRN REV MOUNT SMD 058212
DS11 LED GRN REV MOUNT SMD 058212
DS12 LED GRN REV MOUNT SMD 058212
DS13 LED GRN REV MOUNT SMD 058212
DS14 LED GRN REV MOUNT SMD 058212
DS15 LED GRN REV MOUNT SMD 058212
DS16 LED GRN REV MOUNT SMD 058212
DS17 LED RGB SMD 058209
DS18 LED RGB SMD 058209
DS19 LED RGB SMD 058209
DS20 LED RGB SMD 058209
DS21 LED RGB SMD 058209
DS22 LED RGB SMD 058209
DS23 LED RGB SMD 058209
DS24 LED RGB SMD 058209
IR1 IR SENSOR 38KHZ 3V-5V 121066
J1 HEADER 2 PIN LATCHING 117766
J2 HEADER 2 PIN LATCHING 117766
J3 CONN 23 PIN FFC SMD 118004
J4 CONN 8 PIN FFC SMD 118118
J5 CONN 8 PIN FFC SMD 118118
J6 CONN 8 PIN FFC 117915
J7 CONN 8 PIN FFC 117915
J8 CONN 9 PIN FEMALE BOTTOM MOUNT 117987
J9 CONN 12 PIN FFC SMD 118001
J10 CONN 12 PIN FFC SMD 118001
J11 CONN 12 PIN FFC RA SMD 117990
J12 CONN 12 PIN FFC RA SMD 117990
J13 JACK HEADPHONE STEREO 1/8IN 117945
L1 INDUCTOR 10UH 30% SMD 122438
MP1 SPACER LED 4MM LEN 163186
PCB1 PC BD DISPLAY 130336
R1 RES SMD0805 22.1 1/8W 1% 145003
R2 RES SMD0805 150 1/8W 1% 145019
R3 RES SMD0805 6.81K 1/8W 1% 145029
R4 RES SMD0805 475K 1/8W 1% 145040
R5 RES SMD0805 150 1/8W 1% 145019
R6 RES SMD0805 12.1K 1/8W 1% 145030
R7 RES SMD0805 1.21K 1/8W 1% 145021
R8 RES SMD0805 2.74K 1/8W 1% 145025
R9 RES 4.42K 1% .125W 0805 SMD 145121
R10 RES SMD0805 2.74K 1/8W 1% 145025
R11 RES SMD0805 2.74K 1/8W 1% 145025
R12 RES SMD0805 2.74K 1/8W 1% 145025
R13 RES SMD0805 2.74K 1/8W 1% 145025
R14 RES SMD0805 2.74K 1/8W 1% 145025
R15 RES SMD0805 2.74K 1/8W 1% 145025
R16 RES SMD0805 2.74K 1/8W 1% 145025
R17 RES SMD0805 2.74K 1/8W 1% 145025
R18 RES SMD0805 2.74K 1/8W 1% 145025
R19 RES SMD0805 2.74K 1/8W 1% 145025
R20 RES SMD0805 2.74K 1/8W 1% 145025
R21 RES SMD0805 2.74K 1/8W 1% 145025
R22 RES SMD0805 2.74K 1/8W 1% 145025
R23 RES SMD0805 2.74K 1/8W 1% 145025
R24 RES SMD0805 1.5K 1/8W 1% 145022
R25 RES SMD0805 3.92K 1/8W 1% 145027
R26 RES SMD0805 1.5K 1/8W 1% 145022
R27 RES SMD0805 3.92K 1/8W 1% 145027
R28 RES SMD0805 3.92K 1/8W 1% 145027
R29 RES SMD0805 1.5K 1/8W 1% 145022
