McIntosh MP1100

72
Ref. No. Description Part No.
DSPLY/STBY PSHBTN/MUTE PSHBTN/L MTR/R MTR PCB 751912 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
R30 RES SMD0805 3.92K 1/8W 1% 145027
R31 RES SMD0805 1.5K 1/8W 1% 145022
R32 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R33 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R34 RES SMD0805 1.5K 1/8W 1% 145022
R35 RES SMD0805 3.92K 1/8W 1% 145027
R36 RES SMD0805 1.5K 1/8W 1% 145022
R37 RES SMD0805 3.92K 1/8W 1% 145027
R38 RES SMD0805 3.92K 1/8W 1% 145027
R39 RES SMD0805 1.5K 1/8W 1% 145022
R40 RES SMD0805 3.92K 1/8W 1% 145027
R41 RES SMD0805 1.5K 1/8W 1% 145022
R42 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
R43 POT 1/4” HORIZ 1K OHM 1/2W SMD 134518
S1 ENCODER ROTARY W/ DETENT & PB 146272
S2 ENCODER ROTARY W/ DETENT & PB 146272
S3 SWITCH TACT 260GF 5MM SMD 150072
S4 SWITCH TACT 260GF 5MM SMD 150072
U1 IC SINGLE NAND SCHMITT SMD 133724
U2 IC SINGLE NAND SCHMITT SMD 133724
