47
Cinema 2
The Front Panel Alphanumeric Display will indicate CIN-
EMA 2 and the appropriate Front Panel Operating Mode
Display LEDs will illuminate. Refer to figure 56. This pro-
vides DTS NEO:6 processing Analog Signals and 2-Chan-
nel Digital Signals. It also decodes DTS-ES Signals.
External
All internal signal processing is bypassed and the eight
Rear Panel EXTERNAL INPUTS are activated so the
MX135 performs as an Eight Channel Preamplifier for an
external source or processor. The Front Panel Alphanu-
meric Display indicates EXTERNAL. Refer to figure 57.
Note: Approximately 3 seconds after selecting EXTERNAL
SURROUND MODE, the Front Panel Alphanumeric
Display will change, indicating EXTERNAL, to the
normal display of INPUT A, INPUT B and percentage
of VOLUME.
Figure 57
How to Operate the Surround Mode, con’t
Figure 55
Figure 56
