McIntosh MX135

56
How To Clear an Assigned Station Preset
1. Press ENTER Push-button.
2. Press the Front Panel PRESET Left and Right
Push-buttons to select the Preset Station that will be
removed from memory.
3. Press and Hold the ENTER Push-button for approxi-
mately 3 seconds until the Front Panel Alphanumeric
Display indicates the word CLEARED. Refer to figure
68.
Note: If you wish to replace an already assigned Station
Preset with another radio station, it is not necessary
to clear the Preset first, just enter in the new station
for that Preset. The new station will automatically
replace the previously assigned station.
4. To clear any additional Station Presets perform steps 1
through 3 again.
How to Assign Preset Stations
The MX135 AM/FM Tuner Module (TM1) allows for pre-
setting radio stations into memory. To enter Presets follow
the below steps:
Note: If there are no Presets Assigned and either the Front
Panel PRESET Push-buttons or the Remote Control
REVIEW Push-button are pressed, the MX135 Front
Panel Alphanumeric Display will indicate NO
PRESETS. Refer to figure 65.
1. Select either the AM or FM Broadcast Band.
2. Press the Front Panel TUNING Up


 or Down


 Push-
button to select a station.
3. Momentarily press and release the Front Panel ENTER
Push-button. The Front Panel Alphanumeric Display
will indicate 1 AVAILABLE, which is the first of 9
Preset Numbers that can be assigned. The Station that
is about to be entered into memory may also assigned
to a different Preset Number (2-9) by pressing the
PRESET Left and Right Push-buttons to select the
desired Preset Number. Refer to figure 66.
Note: Presets are automatically assigned in order from 1 to
9 unless a different Preset Number is selected.
4. Press and release the Front Panel ENTER Push-button a
second time to store the Preset into memory. The just
entered Station Preset Selection will be assigned Preset
Number 1 which is displayed on the far right side of
the Front Panel Alphanumeric. Refer to figure 74.
5. Assign additional station Presets by performing steps 1
through 5 until a total of 9 AM and 9 FM Station Pre-
sets have been assigned. Each time you assign an addi-
tional Preset Number, the Front Panel Alphanumeric
Display will indicate the number of the next available
Preset.
Note: If all 9 Presets are assigned and the ENTER Push-
button is pressed, the display will indicate the station
selected for Preset Number 1.
How to Assign Preset Stations
Figure 65
Figure 68
Figure 66
Figure 67
6. To verify the Station Preset(s) just entered into
memory, press the PRESET Left and Right Push-
buttons to cycle through and confirm your preset as-
signments.
