21
TECHNICAL SPECIFICATIONS
Operating temperature
10 to 42 °C (50 to 107 °F)
Operating humidity
20 to 85 % rH, non-condensing
Storage Humidity
5 to 95 % rH, non-condensing
Altitude during operation
3000 m (with power supply) 4000 m (without power supply)
Altitude during transport
4000 m
Storage temperature
0 to 50 °C (32 to 122 °F) -30 to 70 °C (-22 to 158°F) during
transport, 24 hour max.)
Sample volume 10 L
Linear measurement range 1.2–25.5 g/dL (12–255 g/L)
Wavelength Multiple wavelengths ranges, 450 nm to 750 nm
Measuring time 1 second
Displayed result
Hemoglobin, optional calculated Hematocrit*
Memory Up to 4,000 results with date and time*
Battery
Instrument input rating
3.6 V integrated lithium-ion rechargeable batteries
5 V, 100 mA (PC) / 350 mA (USB power supply)
Power supply input rating
Mains Adaptor: Input: 4.5 – 5 VA, 100–240 V AC, 50–60 Hz
Output: 350 mA
Suitable Power supply: Model: CUI, SMI5-5-V-I38 USB The
adapter is only for indoor use
Data interface
USB 2.0, Bluetooth® Smart* Equipment connected to the
interface must be compliant to IEC 60950 or IEC 62368
Overvoltage category II
Pollution degree 2
Duration of use
40 days / 10,000 tests of continuous use, Standby time: 9 months
for a fully charged battery
Analyzer dimensions L = 6 in, W = 3.5 in, H = 1.6 in
Analyzer weight 0.4 lb
Dimensions of transport box
L = 9 in, W = 6.5 in, H = 2.8 in
1.3 lb
*) Function requires activation by EKF Link light / EKF Link software, see section 6.2 for details.
CONSULT
®
HEMOGLOBIN TESTING SYSTEM USER MANUAL
