52 IMM AGS-2
Figure 29, AGS 165CM/B – AGS 175CM/B (with Remote Evaporator)
0.875
KNOCK OUT
( QTY 4 TOTAL)
330712801D030A
AGS-C-165-175
263.0 (6680.2)
SUCTION
CONNECTION
(3.12 O.D.)
(2) POWER
ENTRY
FIELD CONTROL
(2) CONNECTIONS
100.4
(2550.2)
88.5 (2247.9)
LIQUID
CONNECTION
( 1.38 O.D.)
Figure 30, AGS 180CM/B - AGS 190CM/B (with Remote Evaporator)
0.875
KNOCK OUT
( QTY 4 TOTAL)
330712801D020C
AGS-C-180-190
224.8 (5709.9)
LIQUID CONNECTIONS
LIQUID
CONNECTION
( 1.38 O.D.)
SUCTION
CONNECTION
(3.62 O.D.)
(2) POWER
ENTRY
FIELD CONTROL
(2) CONNECTIONS
100.4
(2550.2)
88.5 (2247.9)
