4 Pipes System Specification (220V ~ 240V – 50 Hz)
Model MCW200H MCW300H MCW400H MCW600H MCW800H MCW1000H MCW1200H
High m
3
/h 408 595 765 1138 1427 1699 2175
Medium m
3
/h 340 510 680 1104 1240 1495 1869
Air flow
Low m
3
/h 272 340 595 765 1037 1087 1529
W 2260 3360 4240 6520 8170 9190 11910
Total
Btu/h 7710 11460 14460 22240 27870 31350 40630
W 1500 2300 2850 4400 5410 6240 8010
Cooling
Capacity
Sensibl
e
Btu/h 5110 7840 9720 15010 18450 21290 27330
Heating Capacity W 3570 5040 7230 9760 12800 14450 18790
1-Row Heating Capacity W 1410 2300 3350 4430 5200 7010 8570
3-Row l/min 7(0.41) 10(0.57) 13(0.78) 19(1.08) 24(1.39) 26(1.56) 32(1.92)
Water Flow
1-Row (m
3
/hr) 4(0.24) 4(0.24) 4(0.24) 4(0.24) 4(0.24) 9(0.50) 9(0.50)
3-Row 16 13 22 47 33 26 45
Head Loss
1-Row
kPa
8 8 15 17 21 18 20
Fan
Type Centrifugal fan (forward-curved galvanized steel fan wheels)
Number of Fans 1 1 2 2 3 3 4
Fan Housing Galvanized steel 0.5mm
Coil
Type Seamless copper tube mechanically bonded to configurated aluminium fin
Routine Testing Pressure .
Motor
Type Split-capacitor motor with ball bearing
Number of Motors 1 1 1 1 2 2 2
Rated Voltage 220-240V~
Rated Frequency 50Hz
Rated Input 60Pa
W
55 77 95 155 207 221 285
power 80Pa
W
59 84 101 159 213 225 287
Insulation Class E
Pipe Connection Rc3/4
Drain Pipe R 3/4
Length mm 714 884 1014 1214 1464 1564 1824
Width mm 490 (without Plenum) / 556 ( with Plenum)
Dimension
Height mm 251
Net Weight kg 20 24 28 32 44 47 49
Net Weight (Plenum) kg 22 27 31 36 48 52 56
Conditions:
Cooling Capacity: Entering air temp.27℃ (DB*),19.5℃ (WB**); Entering water temp. 7℃, Leaving water temp. 12℃
Heating Capacity: Entering air temp. 21℃ (DB); Entering water temp. 60℃, the same amount of water flow with cooling.
Air Flow: Under dry coil conditions, fan speed high weight: Not include packing
* DB: Dry Bulb **WB: Wet Bulb
