McQuay MCW 200 C User Manual

Outlines and Dimensions
Figure 2
WATER I NLET
CAUTION
BE CAREFUL NOT TO DAMAGE THE
CONNECTOR WITH TIGHT FORCE
WHEN PIPING.
WATER OUTL ET
WAT ER OUTL ET
CONNECTOR WITH TIGHT FORCE
BE CAREFUL NOT TO DAMAGE THE
CAUTI ON
WATER I NLET
WHEN PIPING.
WATER I NLET
CAUTI ON
BE CAREFUL NOT TO DAMAGE THE
CONNECTOR WITH TIGHT FORCE
WHEN PIPING.
WATER OUTL ET
DIMENSION
UNIT SIZE
A B
MCW200C 507 467
MCW300C 677 637
MCW400C 807 767
MCW600C 1007 967
MCW800C 1257 1217
MCW1000C 1357 1317
MCW1200C 1617 1577
A
Unit size
Standard
Drain
pan
Long
Drain
pan
B C D
Number
of Fans
MCW200C 714 814 448 487 505 1
MCW300C 884 984 618 657 675 1
MCW400C 1014 1114 748 787 805 2
MCW600C 1214 1314 948 987 1005 2
MCW800C 1464 1564 1198 1237 1255 3
MCW1000C 1564 1664 1298 1337 1355 3
MCW1200C 1824 1924 1558 1597 1615 4
Figure 1
Page 25
