General Information
This manual has been prepared as guidance for installing and maintaining the McQuay fan coil unit.
McQuay has produced a quality product that will effectively meet your application. However, proper
installation and maintenance procedures must be followed to realize the full capability and life of the unit.
Nomenclature
MCW 200 C D 0 R B F A/N AA - E
Export
Description of Products:
AA – Standard Drain Pan
AF – Extended Drain Pan
AG – Extended Drain Pan + 2 Way Valve
AH – Extended Drain Pan + 3 Way Valve
AI – Standard Drain Pan + 2 Way Valve
AJ – Standard Drain Pan + 3 Way Valve
AK – Standard Drain Pan + Controller
AL – Extended Drain Pan + Controller
AM – Extended Drain Pan + 2 Way Valve + Controller
AN – Extended Drain Pan + 3 Way Valve + Controller
AO – Standard drain Pan + 2 Way Valve + Controller
AP – Standard Drain Pan + 3 Way Valve + Controller
Power Supply: A – 220V/1P/50Hz
K – 115V/1P/60Hz
N – 208-230V/1P/60Hz
Filter (Omitted if without filter)
Return air plenum: B – Plenum back inlet (Standard)
D – Plenum bottom inlet
Pipe connection: R – Right-hand (Standard)
L – Left-hand
External Static Pressure: 0: 0Pa 3: 30Pa
6: 60Pa 8: 80Pa
Electric heater
Design Series: “C” is for 2 pipes system
“H” is for 4 pipes system
Nominal Air Flow (CFM)
McQuay Horizontal Ceiling Concealed Fan Coil Unit
