COOLING CAPACITY (Btu/h) 3 Rows Coil
Entering Entering Air Temperature ºF (ºC)
Water Water Flow W.P.D DB = 75.2(24) DB = 77(25) DB = 78.8(26) DB = 80(26.7) DB = 80.6(27) DB = 80.6(27) DB = 82.4(28)
Temp. WB = 62.6(17) WB = 64.4(18) WB = 66.2(19) WB = 67(19.4) WB = 67.1(19.5) WB = 68(20) WB = 69.8(21)
Model
ºF (ºC) l/min kPa TH SH TH SH TH SH TH SH TH SH TH SH TH SH
26 22.44 33475 24840 36670 25685 39945 26505 41470 27670 41705 27850 43320 27285 46785 28040 32 32.93 35655 25765 39095 26700 42725 27645 44370 28850 44630 29040 46370 28520 50270 29415 38 45.23 37350 26490 40965 27495 44805 28515 46540 29760 46815 29955 48660 29460 52650 30380
MCW1200C 41 (5)
44 59.30 38580 27035 42425 28125 46315 29155 48120 30420 48400 30620 50350 30165 54520 31145
26 22.44 31065 23820 34110 24635 37365 25460 38870 26620 39110 26805 40710 26255 44155 27015 32 32.93 32985 24630 36400 25570 39915 26490 41540 27700 41795 27885 43545 27375 47375 28265 38 45.23 34500 25270 38105 26285 41890 27300 43610 28540 43880 28735 44360 27700 49795 29225
MCW1200C 42.8 (6)
44 59.30 35745 25800 39480 26865 43435 27940 45230 29210 45505 29405 46025 28375 51570 29940
26 22.44 28615 22815 31660 23640 34870 24475 36380 25640 36620 25825 38070 25230 41485 26000 32 32.93 30280 23500 33670 24455 27155 25380 38770 26580 39025 26770 40760 26275 44465 27135 38 45.23 31690 24085 35265 25110 38955 26100 40650 27340 40915 27530 42845 27095 46775 28035
MCW1200C
44.6 (7)
44 59.30 32785 24545 36505 25620 40410 26690 42180 17960 42460 28155 44480 27755 48580 28745
26 22.44 26090 21795 29175 22655 32265 23455 33770 24630 34005 24815 35545 24265 38920 25040 32 32.93 27645 22420 30895 23340 34360 24270 35960 25480 36210 25670 37930 25175 41610 26045 38 45.23 28840 22910 32385 23935 36045 24935 37730 26170 37995 26365 39825 25905 43730 26850
MCW1200C 46.4 (8)
44 59.30 29850 23320 33535 24400 37350 25455 39110 26720 39380 26915 41370 26510 45445 27515
26 22.44 23445 20745 26515 21620 29745 22495 31250 23670 31485 23855 32985 23305 36230 24055 32 32.93 24980 21350 28215 22280 31635 23215 33230 24430 33485 24615 35070 24085 38720 24965 38 45.23 26035 21775 29465 22770 33095 23780 34770 25020 35035 25210 36845 24760 40715 25710
MCW1200C 48.2 (9)
44 59.30 26870 22110 30530 23190 34310 24250 36050 25520 36325 25715 38225 25290 42270 26295
26 22.44 20325 20030 23890 20615 27015 21470 28500 22650 28730 22830 30335 22325 33635 23120 32 32.93 21685 20470 25500 21230 28875 22165 30470 23380 30725 23570 32295 23045 35905 23935 38 45.23 23200 20650 26600 21650 30190 22660 31860 23900 32120 24095 33825 23615 37660 24575
MCW1200C 50 (10)
44 59.30 23925 20935 27470 21990 31225 23060 32950 24320 33225 24515 35105 24095 39120 25115
Page 17
Fan speed correction factor
W.P.D: Water Pressure Drop Dry Bulb ** WB: Wet Bulb
Medium Low
MODEL
Total Sensible Total Sensible
MCW1200C 0.89 0.87 0.75 0.70
TH: Total Heat SH: Sensible Heat Fan Speed: High 1 Btu = 0.2928104 W
