McQuay MCW200D User Manual

16
MODEL 200D 300D 400D 500D 600D
1 TOP PLATE PART NO. M01014060791 M01014060792 M01014060793 M01014060795 M01014060860
2 FAN DECK PART NO. M01014060801 M01014060802 M01014060803 M01014060805 M01014060804
3 DRAIN GUIDE PLATE PART NO. M01014060811 M01014060812 M01014060813 M01014060815 M01014060890
4 PLENUM PART NO. M50014060111 M50014060112 M50014060113 M50014060115 M50014060114
5 COIL PART NO. M50024060000 M50024060001 M50024060002 M50024060052 M50024060050
6 FILTER PART NO. M03084066140 M03084066141 M03084066142 M03084066143 M03084066144
7 MOTOR PART NO.
YDK36-4Be
M03034065200
YSK56-4B4
M03034065201
YSK71-4B4
M03034065202
YSK100-4B4
M03034065203
YSK150-4B6
M03034065204
7 MOTOR PART NO. \ \ \ \ \
8 FAN,CENTRIFUGAL M03029000980 M03024060001 M03029000980 M03029000980 M03029000980
8 FAN,CENTRIFUGAL \ M03024060002 M03029000981 M03029000981 M03029000981
9 DRAIN PAN STD M50014063167 M50014063831 M50014063169 M50014063689 M50014063170
9 DRAIN PAN ETD100 M50014063738 M50014063746 M50014063740 M50014063745 M50014063741
9 DRAIN PAN ETD200 M50014063001 M50014063009 M50014063003 M50014063004 M50014063005
10 HEADER,OUTLET M02124061141 M02124061141 M02124061141 M02124061097 M02124061097
11 HEADER,INLET M02124061142 M02124061142 M02124061142 M02124061198 M02124061198
MODEL 800D 900D 1000D 1200D 1400D
1 TOP PLATE PART NO. M01014060796 M01014060797 M01014060798 M01014060796 M01014060798
2 FAN DECK PART NO. M01014060806 M01014060807 M01014060808 M01014060809 M01014060810
3 DRAIN GUIDE PLATE PART NO. M01014060816 M01014060817 M01014060818 M01014060816 M01014060818
4 PLENUM PART NO. M50014060116 M50014060117 M50014060118 M50014060119 M50014060120
5 COIL PART NO. M50024060054 M50024060055 M50024060007 M50024060060 M50024060061
6 FILTER PART NO. M03084066145 M03084066146 M03084066147 M03084066148 M03084066149
7 MOTOR PART NO.
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YSK240-4B8
M03034065206
YSK280-4B8
M03034065208
7 MOTOR PART NO.
YDK71-4B4
M03034065205
YDK71-4B4
M03034065205
YSK150-4B6
M03034065204
YDK95-4B6
M03034065207
YDK125-4B6
M03034065209
8 FAN,CENTRIFUGAL M03034065204 M03034065204 M03024060001 M03024060003 M03024060003
8 FAN,CENTRIFUGAL M03034065205 M03034065205 M03024060002 M03024060004 M03024060004
9 DRAIN PAN STD M50014063171 M50014063172 M50014063832 M50014063171 M50014063832
9 DRAIN PAN ETD100 M50014063742 M50014063743 M50014063747 M50014063742 M50014063747
9 DRAIN PAN ETD200 M50014063006 M50014063007 M50014063010 M50014063006 M50014063010
10 HEADER,OUTLET M02124061099 M02124061099 M02124061099 M02124061138 M02124061138
11 HEADER,INLET M02124061100 M02124061100 M02124061100 M02124061139 M02124061139
