Ball Weight
When loading your caravan, the ideal ball weight once loaded is approximately 10% of the total weight of the
caravan. Use a ball weight scale to identify the ball weight and load the caravan in a manner that achieves the desired
10%. Ideally, once loaded the rst time, take the caravan to a weigh bridge, and measure the total weight loaded
including the weight on the jockey wheel. When the total weight is known, adjust the load locations to meet the
desired 10%.
Effects of Weight Distribution
The distribution of weight in a caravan can inuence the handling and performance of the van. Overloading the front
or rear may cause adverse handling and sway. Additionally, overloading the front or back can induce a pendulum
effect that can cause dangerous sway and cause an accident.
Tyre Pressures
Tyre pressures have a large effect on the handling of your caravan. Tyres that are under the recommended pressure
for the caravans’ actual weight can cause a dangerous sway. It is important to follow the correct pressure guide.
The guide below indicates pressure for the ATM which includes ball weight of 10%. Pressures are cold ination
applicable to the standard Goodride 265/75R16 tyres tted.
Actual Weight
Pressure PSI
Single Axle
Pressure Kpa
Single Axle
2000kg 52psi 358Kpa
2100kg 54psi 372Kpa
2200kg 57psi 393Kpa
2300kg 59psi 406Kpa
2400kg 62psi 427Kpa
2500kg 64psi 441Kpa
2600kg 67psi 462Kpa
2700kg 70psi 482Kpa
2800kg 72psi 496Kpa
2900kg 75psi 517Kpa
3000kg
