Kitchen
Before sliding out kitchen, raise the pad bolt and turn to lock in the up position (Fig: 2) Push down blue latch on the slide
mechanism and pull kitchen out. (Fig: 2a)
When kitchen is extended t the support leg into its receiver (Fig: 3)
Extend support leg and secure locking screw (Fig: 3a)
CAUTION – Use of the slide out kitchen cooktop without the annex or awning
may adversely affect the safety and operation of the appliance.
CAUTION
