NOTES*
Expectations of a 300 watt solar charging system need to be reasonable. Running two fridges without adding
additional solar and following best practice with pre-cooling and packing will greatly reduce battery life and the
ability of the solar panels to keep up with power needs.
Using inverters will very quickly diminish battery capacity.
Charging from Tow Vehicle
Symptom Possible Cause Remedy
No charge Alternator light not
showing on DC to DC
Tripped breaker
Reset circuit breaker CB5 in Fig. 1 &
Fig. 3
Tripped breaker in car circuit Check car circuit breaker/fuse Fig. 6
No charge, alternator, and solar light
both on
Trigger wire for DC to DC unit not
activated
Connect trigger wire for DC to DC
to accessory power from car via
trailer plug. Fig. 5
No charge DC to DC alternator lit
Tripped breaker
Reset circuit breaker CB4 Fig. 1 &
Fig. 3
Trigger wire for DC to DC unit not
activated for smart alternator
Connect trigger wire for DC to DC
to accessory power from car via
trailer plug. Fig. 5
Charging from Mains Power
Symptom Possible Cause Remedy
No power to charger
Mains power not connected Connect mains power
Charger not plugged in Plug in mains charger
Charger not turned on Turn on charger
RCD tripped Reset RCD Fig 1
No charge with charger on
Tripped circuit breaker
Reset circuit breaker CB3 Fig.1 &
Fig. 3
Incorrect charger setting
Set charger to correct battery type
and power setting (AGM for stan-
dard batteries)
Battery voltage too low (less than 6
volts)
Change charger setting to “Supply”
until battery voltage reads minimum
of 6 volts then choose setting “re-
condition” if this function is avail-
able. Choose “AGM” if not available.
If error code appears on the charger display refer to the Projecta user manual.
