DC8xD MK3 GENSET CONTROLLER USER MANUAL
30
The action after the primary
maintenance expired.
When it is set to enabled, when the
generator set meets the closing
conditions, it will be loaded
automatically.
2)Delay time setting
The time during the genset starts after the
mains failure or remote signal is valid.
The time needed to be preheat before the
starter on power.
The time when the starter is on power.
If crank failure, the waiting time before the
second test time.
When the crank condition contains oil
pressure, if the oil pressure is higher than the
preset value and continue for few seconds,
then it is regarded as crank success.
Low oil pressure, high water temperature,
under speed, under frequency, under voltage,
charge failure are all invalid during this time
except for emergency stop and over speed.
Idle running time when crank successfully.
The longest speed-up time, during which time
the system will exit once speed increased
successfully.
The time needed for loading.
To avoid the switch actions if the mains
unstable. If the remote start signal is invalid
(DC8XD MK3will check if the mains normal),
genset will not switch immediately, after the
delay time, it will transfer to mains. during the
delay, if the remote start signal is valid, then
genset will come into rated running.
There shall be loading delay from Mains to
Gens if the remote start signal valid or Mains
abnormal under Cooling time.
After unloading, the time of cooling down by
radiator before stop. during the delay, if the
remote start signal is valid, then genset will
come into rated running.
Stop solenoid on power time.
If the RPM is 0 during the stop failure time,
then the stop failure time is no needed.
