DC8xD MK3 GENSET CONTROLLER USER MANUAL
34
7.Remote start(with load): the gens comes into
start procession if this signal is valid and under
auto mode.
8.Soundproof alarm: audio alarm output is
disabled if there is signal output.
(Functional of
PIN 12)
pressure alarm
switch.)
12
AUX. INPUT 4
(Functional of
PIN 13)
0-8(4. Low fuel
level warning
input)
14
AUX. INPUT 5
(Functional of
PIN 14)
0-8(3. Low
water level
alarm switch)
7
AUX. INPUT 1
valid
0- Normal close
1- Normal open
The status of switch value input valid.
9
AUX. INPUT 2
valid
0- Normal close
1- Normal open
11
AUX. INPUT 3
valid
0- Normal close
1- Normal open
13
AUX. INPUT 4
valid
0- Normal close
1- Normal open
15
AUX. INPUT 5
valid
0- Normal close
1- Normal open
5)Mains protection
No
Parameter
Range(defaults)
Notes
1
Phase
Disable
1 Phase 2 Wire
2 Phase 3 Wire
3 Phase 3 Wire
3 Phase 4 Wire
Choose the input, there is no display if setting
as disable.
2
Mains under volt
55-330V(184V)
When the mains voltage is lower than the "low
voltage crank threshold" and comes into
mains low voltage delay (normal failure delay)
but still lower, then mains becomes invalid. If
the voltage become higher than "low voltage
revert threshold" during normal failure delay
time, then it will not alarm.
3
Revert under volt
55-330V(207V)
4
Mains over volt
55-330V(276V)
When the mains voltage is higher than the"
high voltage crank threshold" and comes into
mains high voltage delay (normal failure
delay) but still higher, then mains becomes
invalid. If the voltage become lower than "low
voltage revert threshold" during normal failure
delay time, then it will not alarm.
5
Revert over volt
55-330V(253V)
6
Mains normal
delay
0.0-3600.0S (10.0s)
The time from abnormal to normal, which is
used for ATS transfer.
7
Mains abnormal
delay
0.0-3600.0S (5.0s)
6)LCD setting
No
Parameter
Range(defaults)
Notes
1
Start screen
display time
0-20.0s(5.0s)
Start screen display time,0: No-display.
2
Lightness of
20-100%(100%)
Lightness adjustment.
