Mebay DC8-D MK Series User Manual

DC8xD MK3 GENSET CONTROLLER USER MANUAL
33
NO
Parameter
Range(defaults)
Notes
1
AUX. OUTPUT
1(Functional of
PIN 6)
0-20
(4. Preheat
mode 1)
0.Disable.
1.Public warning output: when there is any
warning output.
2.Public alarm output: when there is any alarm
output, alarm locks till revert back.
3.Audio alarm: when there is any alarm output, the
Audio controls.
4.Preheat mode 1: preheat before start.
5.Preheat mode 2: preheat before crank success.
6.Preheat mode 3: preheat after safety delay.
7.Preheat mode 4: preheat till temperature-up end.
8.Preheat mode 5: preheat till temperature-up end,
but no preheat when motor starts.
9.Fuel output: output once gens starts and off till
stable.
10.Crank output: output once cranking, no output
in other mode.
11.Genset running: output under running, off once
RPM is lower than cranking RPM. The crank
success condition can be set.
12.Idle speed control 1: used for speed controller,
there is output under idle but no output under
high speed.
13.Rated running: there is output under rated
running.
14.Gens load: continuous or pulse type according
to time setting.
15.Gens unload: continuous or pulse type
according to time setting.
16.E.S.T. hold: shutdown output, it is used for gens
with stop solenoid. when the setting value of
shutdown delay is over, then it is off.
17.Fuel pump output: there is output if the oil
capacity is lower than start condition for 10s and
shutdown if it is higher than the shutdown
condition for 1s.
18.Mains loading: continuous or pulse type
according to time setting. Not for DC80D MK3.
19.Mains unloading: continuous or pulse type
according to time setting. Not for DC80D MK3 .
20.Public un/loading: continuous(loading) or
unloading.
2
AUX. OUTPUT
2(Functional of
PIN 7)
0-20
(2. Public alarm
output)
3
AUX. OUTPUT
3(Functional of
PIN 8)
0-20
(16. Fuel pump
output)
4
AUX. OUTPUT
4(Functional of
PIN 27,28)
0-20
(DC80D MK3:12
Idle speed
control 1)
(DC82D MK3:19
Mains loading)
5
AUX. OUTPUT
5(Functional of
PIN 29,30)
0-20
(14. Gens load)
6
AUX. INPUT 1
(Functional of
PIN 10)
0-8 (7. Remote
start (with load)
0.Disable.
1.Low oil pressure alarm switch.
2.High temperature alarm switch.
3.Low water level alarm switch.
4.Low fuel level warning input.
5.External instant warning input.
6.External instant alarm input.
8
AUX. INPUT 2
(Functional of
PIN 11)
0-8 (2. High
temperature
alarm switch)
10
AUX. INPUT 3
0-8 (1. Low oil
