Page 133 Speed Level Series - Service & Parts Manual
January 2019Section 9 - Troubleshooting - 3084ES Models
EZ-Cal Adjustment
Refer to “EZ-Cal Scan Tool” on page 127.
Adjustments possible in Access Level 1 Only.
Before changing personalities, ensure that the correct customer and model have been selected in the
SETUPS menu. Any changes to settings will be lost when the model or customer is changed.
To reach ADJUSTMENTS, first access Level 1, then press --> for ADJUSTMENTS. Press Enter, then
press --> to scroll through the sub-menus.
Once the desired sub-menu is found, press Enter again, then --> to scroll through the personalities.
Press the Up or Down arrows to change the personality. Press ESC to go back one or more levels to
reach other sub-menus.
Operation ID Personality Factory Setting Explanation
5A
DRIVE - PLATFORM
STOWED
5A-1 FWD Min 5% Slowest speed possible
5A-2 FWD Max 95% Maximum speed potential
5A-3 REV Min 5% Slowest speed possible
5A-4 REV Max 95% Maximum speed potential
5A-5 ACCEL 1.5 sec Ramp-up time to maximum
5A-6 DECEL 1.0 sec Ramp-down time to stop
5A-7 MAX Height 101% Maximum drivable height
5A-8 Positrack Not Used Not Used
5A-9 Positrack Not Used Not Used
5B
DRIVE PLATFORM
ELEVATED
5B-1 FWD Min 5% Slowest speed possible
5B-2 FWD Max 23% Maximum speed potential
5B-3 REV Min 5% Slowest speed possible
5B-4 REV Max 23% Maximum speed potential
5B-5 ACCEL 1.5 sec Ramp-up time to maximum
5B-6 DECEL 5.0 sec Ramp-down time to stop
5C
LIFT
5C-1 UP Min 5% Slowest speed possible
5C-2 UP Max 60% Maximum speed potential
5C-3 DOWN Min 0% (not used) Gravity down (not used)
5C-4 DOWN Max 0% (not used) Gravity down (not used)
5C-5 ACCEL 1.2 sec Ramp-up time to maximum
5C-6 DECEL 0.5 sec Ramp-down time to stop
5C-7 MAX Height ANSI: 101% CE: 100% Maximum elevated height potential
5C-8 Armguard --> Time 0.0 sec CE Spec. Machines Only
5C-9 Armguard --> @ Height 101% CE Spec. Machines Only
5D
STEER
5D-1 Speed 30% Maximum speed potential
5D-2 Drive Compensation 30% Adds additional to drive speed
5D-3 Drive Comp Elevated 20% Adds additional to drive speed elevated
5D-4 ACCEL 0.2 sec Ramp-up time to maximum
5D-5 DECEL 0.2 sec Ramp-down time to stop
5E - DECK 5E- Not Used Not Used Power-out deck (not used)
