Mec 3084RT - Section 13 - Boom

Page 204 Speed Level Series - Service & Parts Manual
January 2019Section 12 - Platform and Rails
Item Part Number Description Qty.
1 83083 Boom Assembly REF
2
83080 / 83160 Platform Assembly, 3084 REF
83097 Platform Assembly, 2684 REF
3
19258 Ladder, Side-Bolted 1
19148 Ladder, Top-Bolted 1
4 50040 Bolt, M12 x 35, GR8.8 10
5 50003 Washer, 13.5 mm ID x 24mm OD 14
6 50054 Nut, M12, GR8.8 14
7 50039 Bolt, M12 x 30 4
REF - Reference
