Page 9 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
ART_3089
Control Module
Power Module
Battery
Disconnect Switch
Alarm
Terminal Block
Module
GP400 Module
12 Volt DC Battery
Emergency
Lowering Switch
Lower Controls
Hydraulic
Reservoir
Overflow
Reservoir
Radiator
Fuel
Reservoir
Hydraulic Fluid
Filter
Engine Air Intake
Engine Air Filter
Hydraulic Fluid
Sight Gauge
Hydraulic Fluid
Pump
Engine
Relays
Main
Hydraulic
Manifold
Leveling
Hydraulic
Manifold
Power to Platform
AC Connector
