Page 214 Speed Level Series - Service & Parts Manual
January 2019Section 13 - Boom
Item Part Number Description Qty.
-- 83081 Chassis Assembly 1
1 19020 Chassis Weldment 1
2 19031 Boom Mount Weldment 1
3 19013 Level Pivot Weldment 1
4 19124 Pin 2
5 19123 Pin 1
6 18152 Pin Retainer 1
7 50023 Bolt, M12 x 50 6
8 19122 Pin 4
9 50119 Nut, Nylock 1-1/4” 8
10 19081 Cylinder, Level 2
11 50039 Bolt, M12 x 30 1
12 92011 Bearing, Flange 4
13 50007 Washer, M12 Nord-Lock 6
14 50065 Flat Washer, 1¼ 8
15 19164 Spacer 8
16 92201* CAN Tilt Angle Transducer, Model 151 1
17 50125 Screw, M6 x 55 2
18 50047 Nut, M6 Nylock 2
19 50068 Washer, M6 Fender 2
20 92040 Spacer As Needed
* For adapter from early style (1-Plug) CAN Tilt to new style (2-Plug) CAN Tilt use 22538
To Next Page
