Page 220 Speed Level Series - Service & Parts Manual
January 2019Section 13 - Boom
Item Part Number Description Qty.
-- 83082 3084 -- Lower Boom Assembly 1
-- 83095 2684 -- Lower Boom Assembly 1
1
19034 3084 -- Lower Boom Weldment 1
19327 2684 -- Lower Boom Weldment 1
2 -- -- --
3
19049 3084 -- Lower Tension Weldment 1
19329 2684 -- Lower Tension Weldment 1
4 19118 Cylinder Mount Pin 1
5 19084 Lift Cylinder 1
6 50024 Bolt, M10.9 x 65 1
7 19121 Pin, Boom Mount 3
8 18152 Pin Retainer 3
9 50039 Bolt, M12 x 30 3
10 50007 Washer, M12 Nordlock 3
11 50049 Lock Nut, M10 1
12 90844
ANSI Specifications - EZfit Angle Transducer, Model 120 1
CE Specifications - EZfit Angle Transducer, Model 120 2
13 50016
ANSI Specifications - Screw, M8 x 55 2
CE Specifications - Screw, M8 x 55 4
14 92011 Flange Bearing 8
15 50001 M8 Washer 10
16 50048
ANSI Specifications - M8 Lock Nut 4
CE Specifications - M8 Lock Nut 6
17 19199 Gear, Pivot 1
18 91963 Wheel 1
19 -- -- --
20 92012 Flange Bearing, 2.0 x 1.0 2
21
19158 3084 -- Cable Cover 1
19436 2684 -- Cable Cover 1
22 50058 Bolt, HHCS 1”-8 x 8”, GR8, ZP 3
23 50063 Washer, 1” ZP Std Flat 3
24 50064 Washer, 1” ZP Flat XT 3
25 50120 Nut, NNYL 1”-8 3
26 50059 Bolt, 3/4-10 x 5.5 1
27 50062 Washer, 3/4 Std 1
28 50118 Nut, 3/4-10 Jam Nylock
1
29 19240 Spacer, Lower Boom Gear Shield 2
30 19241 Guard 2
31 50031 Bolt, M8 x 25 4
32 19157 Wear Pad 1
33 50124 Cap Screw, M8 x 1.25 x 20, Button Head Allen 2
