Mec 3084RT - Page 229

Page 222 Speed Level Series - Service & Parts Manual
January 2019Section 13 - Boom
Item Part Number Description Qty.
-- 83083 3084 -- Upper Boom Assembly 1
-- 83096 2684 -- Upper Boom Assembly 1
1 19068 Platform Pivot Weldment 1
2
19073 3084 -- Upper Boom Weldment 1
19332 2684 -- Upper Boom Weldment 1
3
19058 3084 -- Upper Tension Weldment 1
19334 2684 -- Upper Tension Weldment 1
4 REF Lower Boom Weldment (See “Lower Boom Assembly” On Page 220) 1
5 REF Lower Tension Weldment (See “Lower Boom Assembly” On Page 220) 1
6 19199 Gear, Pivot 1
7 19055 Boom Pivot Weldment 1
8 92011 Flange Bearing 8
9 -- -- --
10 19121 Boom Mount Pin 6
11 18152 Pin Retainer 6
12 50046 Bolt, M12 x 35 6
13 50058 Bolt, HHCS 1”-8 x 8”, GR8, ZP 3
14 50063 Washer, 1” ZP Std Flat 3
15 50064 Washer, 1” ZP Flat XT 3
16 50120 Nut, NNYL 1”-8 3
17
19158 3084 -- Cable Cover 1
19436 2684 -- Cable Cover 1
18 50001 M8 Washer Standard 4
19 50048 M8 Lock Nut 2
-- -- -- --
21 50007 Split Lock Washer, M12 6
22 19157 Wear Pad 1
23 19183 Grease Port Cover 1
24 50037 Bolt, M12 x 20 2
25 50003 Washer, M12 2
26 50124 Bolt 2
REF - Reference
