Mec 3084RT - Main Manifold Assembly, RT Models - Part 1

Page 230 Speed Level Series - Service & Parts Manual
January 2019Section 14 - Axles
Item Part Number Description Qty.
-- 91319 Wheel Motor W/Brake --
1 9781 Seal Kit --
1a Incl Dust Seal 1
1b Incl Metal Backup Shim 1
1c Incl Backup Seal 1
1d Incl Shaft Seal 1
1e Incl Small Piston O-Ring Seal 1
1f Incl Small Piston Seal 1
1g Incl Large Piston O-Ring Seal 1
1h Incl Large Piston Seal 1
1i Incl O-Ring Seal 1
1j Incl Body Seal 3
1k Incl Manifold Seal 1
1l Incl Commutator Seal 1
1m Incl O-Ring Seal 1
1n Incl Backup Seal 1
-- -- -- --
2 91138 Disk Kit --
2a
Incl Friction Disk 10
91138 Brake Kit 1
2b
Incl Disk Stamping 9
91138 Brake Kit 1
2c
Incl Thick Disk Stamping 2
91138 Brake Kit 1
Incl - Included with Assembly
