Page 234 Speed Level Series - Service & Parts Manual
January 2019Section 15 - Hydraulics
Item Part Number Description Qty.
-- 83072 Manifold Assembly, ES Models --
-- 91743 Manifold W/ Valves, No Fittings, ES Models --
1 91144 Valve, Drive, 4 way 3 Position 1
2 91146 Valve, Steer, 4 Way 3 Position 1
3 91145 Valve, Lift Spool, 3 Way 1
4 91147 Valve, Series Parallel Spool, 4 Way 3 Position 2
5 91150 Valve, Relief, Steer 1
6 91149 Valve, Relief, Lift 1
7 91476 Valve, Relief 1
8 91151 Valve, Piloted Spool 4 Way 3 Position 3
9 91152 Valve, Piloted Poppet 2
10 91012 Valve, Manual — Pull 1
11 91153 Valve, Load Shuttle Check 1
12 91350 Valve, Counterbalance 2
13 91141 Coil, Series 8, 12V 2
14 91142 Coil, Series 10, 12V 1
15 91141 Coil, Series 2
16 91015 Hand Pump, Brake Release 1
17 91351 Flow Divider / Combiner 2
18 91352 Pressure Compensator 1
19 91141 Coil 1
20 REF Cavity Plug 1
21 91354 Orifice Disc 1
22 91355 Orifice Plug, Steer 1
23 91356 Orifice Plug, Flow Divider Bleed 2
24 REF Orifice Plug 2
25 7484 Port Plug M 0.38” O-Ring, RBG-6 2
26 HDW7314 Port Plug M ¼”, O-Ring, RBG-4 19
REF - Reference
