Page 276 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 REF Weldment, Battery Module -- See “Module Installation” On Page 270 --
2 16974 Panel, Battery Module 1
3 16977 Crossbar, Battery Module 1
4 14896 Block, Slide, Door 4
5 25429 Pad 2
6 -- -- --
7 16983 Battery Holddown 1
8 2987 Holddown Rod 2
9 6110 Wingnut 2
10 91641 Battery, 375 AH, UL16 8
11 16619 Bracket, Battery 1
12 16620 Shelf, Battery 5
13 90898 Battery, 12VDC / 17-18 AH 1
14 HDW5724 Screw, 5/16–18, ¾” LG, GR 5 4
15 -- -- --
16 50068 Washer, M6 Fender 17
17 50047 Nut, M6 Nylock 17
18 50028 Screw, Hex, M6 x 20 18
19 91790 Battery Boot, Red, Positive 8
20 91790 Battery Boot, Black, Negative 8
21 91789 Screw, Hex, M8 x 20 4
22 50030 Nut, M8 Nylock 4
23 50061 Washer, 5/16 Flat 4
24 6121 Trim Lock, 1/4” 26
REF - Reference
