Page 286 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 16213 Power Module Weldment REF
2 16247 Guard, Engine Module 1
3 25429 Pad 2
4 40620 Spacer, Insulator 2
5 14896 Slide Block, Door 4
6 14826 Bracket, Cross Support 1
7 50028 Screw, M6 x 20 11
8 50068 Washer, M6 Fender 13
9 50047 Nut, M6 Nylock 12
10 HDW5724 Screw, 5/16 - 18 x 3/4 Inch, GR5 4
11 9370 Level Gauge 1
12 HDW9200 Plug, 1/4 NPT 1
13 6156 Filter Cartridge 1
14 50664 Elbow, MP-MJ90-4-4 2
15 50648 Fitting, MJ-MP-16-20 1
16 6714 Filter Head 1
17 HDW9268 Elbow, 90º 1/4 NPT - 3/4 JIC 1
18 HDW8482 Bolt, 32 × 1.57 6
19 9367 Filler/Strainer 1
20 50893 Tee, MJ-FJX-MJT-6 1
21 50649 Elbow 90, MJ-FJX90-16-16 1
22 50061 Washer, 5/16 Flat 4
23 50920 Fitting, MJ-MP90-6-4 1
REF - Reference
