Page 296 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 16213 Power Module Weldment REF
2 16209 Engine Mount, Diesel 2
3 16210 Spacer 3
4 16207 Bracket, Solenoid Mount 1
5 16345 Bracket, Radiator Mount 2
6 -- -- --
7 91127 Coolant Overflow Tank 1
8 50028 Screw, M6 x 20 2
9 50047 Nut, M6 Nylock 2
10 6458 Hose 3 ft.
11 16295 Air Intake Weldment 1
12 7736 Insulator, Rubber 8
13 40620 Spacer - Isolator 4
14 HDW8567 Washer, Flat, 3/8 4
15 HDW8279 Screw, 3/8 - 16 x 2 1/2 GR8 4
16 HDW8268 Nut, 3/8 - 16 4
17 HDW91234 Screw, M10 - 1.25 x 25 8.8 12
18 91591 Vibration Isolator 1
19 16346 Radiator Brace 1
20 50047 Nut, M6 1
21 90480 Washer, 3/8 x 1-1/2 Fender 4
22 50130 Washer, 1/4 Flat 2
23 50049 Nut, M10 Nylock 5
24 50215 Bolt, M10 x 20 HHCS 5
25 50002 Washer, M10 Flat 5
REF - Reference
