Page 17 Micro 19 - Service & Parts Manual
November 2019Section 10 - Maintenance
Be sure that the battery retainers and cable connections are tight.
Fully charge the batteries. Allow the batteries to rest 24 hours before performing this procedure
to allow the battery cells to equalize.
Check each battery pack and verify that the batteries are wired correctly.
Inspect the battery charger plug and pigtail for damage or excessive insulation wear. Replace
as required.
Connect the battery charger to a properly grounded 110 - 230V / 50 - 60 Hz single phase AC
power supply.
Result: The charger should operate and begin charging the batteries.
Result: If, simultaneously, the charger alarm sounds and the LEDs blink, correct the
charger connections at the fuse and battery. The charger will then operate correctly and
begin charging the batteries.
4.
5.
6.
7.
8.
•
•
NOTE: For best results, use an extension cord of adequate size with a length no longer than
50 ft / 15m.
If you have any further questions regarding the battery charger operation, please
contact the MEC Customer Service.
Electrical Wiring
Maintaining electrical wiring in good condition is essential to safe operation and good machine
performance. Failure to find and replace burnt, chafed, corroded or pinched wires could result in
unsafe operating conditions and may cause component damage.
ELECTROCUTION / BURN HAZARD. CONTACT WITH ELECTRICALLY
CHARGED CIRCUITS COULD RESULT IN DEATH OR SERIOUS INJURY.
REMOVE ALL RINGS, WATCHES AND OTHER JEWELRY.
Inspect the following areas for burnt, chafed, corroded and loose wires:
Ground control panel
Hydraulic power unit module tray
Platform controls
Turn the key switch to ground control and turn the red Emergency Stop button clock-wise to the
on position at both the ground and platform controls
Raise the platform approximately 8 ft / 2.5 m from the ground.
Lift the safety arm, move it to the center of the scissor arm and rotate up to a vertical position.
Lower the platform onto the safety arm.
CRUSHING HAZARD. KEEP HANDS CLEAR OF THE SAFETY ARM WHEN
LOWERING THE PLATFORM.
Inspect the center chassis area and scissor arms for burnt, chafed and pinched cables.
Inspect the following areas for burnt, chafed, corroded, pinched and loose wires:
Scissor arms
1.
•
•
•
2.
3.
4.
5.
6.
7.
•
