Mec Micro 19 - Control System

Page 25 Micro 19 - Service & Parts Manual
November 2019Section 11 - Control System
Control Component Locations
Art_5529
Hydraulic Unit
Steer Valve
Pump Motor
Lift Valve
Platform Controls (PCU)
Component Tray
Hydraulic Unit
Motor Controller / ECU2 (TM1)
Batteries
Lift Up
Limit Switch
Main Power Lower
Emergency Stop Switch
Pothole Switch
(Each Side)
(Inside Wheel Well)
Battery Charger &
Power To Platform
Lower Controls (ECU)
Lift Down
Limit Switch
Drive Motor
(Under Cover)
