Page 4 Micro 19 - Service & Parts Manual
November 2019
Specifications
Working Height* 24 ft 4 in 7.6 m
Platform Height 18 ft 4 in 5.6 m
Maximum Drive Height 18 ft 4 in 5.6 m
Stowed Height
Top Guardrail 79 in 2.0 m
Platform Floor 39 in 1.0 m
Platform Extension Length 23.6 in 0.6 m
Machine Weight** (Unloaded) 2690 lb 1220 kg
Lift Capacity Total 500 lb 227 kg
Deck Extension Capacity 1 Person / 250lb (113 kg)
Maximum Occupants 2
Platform Length (Extended) 78 in 2.0 m
Platform Length (Retracted) 54 in 1.4 m
Width (Overall) 32 in 0.81 m
Platform Dimensions (Length × Width) 53.9 × 27.6 in 1.37 × 0.7 m
Wheel Base 44.5 in 1.13 m
Turning Radius - Inside 17.7 in 0.45 m
Ground Clearance - Stowed 2.4 in 6 cm
Ground Clearance - Elevated 0.6 in 1.5 cm
Drive Speed (Proportional)
Stowed 0-2.5 mph 0-4 km/h
Raised or Extended 0-0.5 mph 0-8 km/h
Gradability 25%/14°
Maximum Side Slope - Stowed 5°
Ground Pressure/Wheel Min/Max 83/112 psi 5.8/7.9 kg/cm
2
Maximum Wheel Load 960 lb 435 kg
Occupied Floor Pressure Full Load Platform Retracted 239 psf 1167 kg/m
2
Occupied Floor Pressure Platform Deck Extended 171 psf 835 kg/m
2
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h)
Tire Size 9 × 4 inch/230 × 100 mm
Wheel Nut Torque 166.7 ft-lb / 226 Nm, Secured with cotter pin
Hydraulic Pressure 2320 psi/ 160 bar
Power System Voltage 24 Volt DC
Battery Charger
Input 110-230 V AC, 50-60 Hz
Output 24 Volt DC
Batteries Two 12 Volt Deep Cycle 115Ah
Airborne Noise Emissions <70 dB
Meets applicable requirements of ANSI A92.6-2006.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
Section 3 - Specifications
Specifications
