November 2019Section 11 - Control System
85
Brake Release Switch
Closed
1930SE/Micro
Turn brake release switch off. Replace brake
release switch.
86 Raised Brake Release Fault 1930SE Only Brake release switch engaged.
87 Brake Release Switch Fault 1930SE Only Brake release switch open.
89 Drive Motor Field Open All Models Check wiring on motors and motor controller.
91 Left Drive Motor Short All Models Check wiring to motor and motor controller.
92 Right Drive Motor Short All Models Check wiring to motor and motor controller.
99 Over 99% Load Warning All Models Platform has reached its weight capacity.
OL Platform Overloaded All Models
Remove the excess load immediately. > 2020 with
overload.
LL
Machine Tilted Beyond Safe
Limits Fault
All Models
Check to see if machine is tilted, then check wiring
to tilt sensor and the tilt sensor.
CH NOT A FAULT CODE All Models Indicates that key switch is in base controls.
