Page 35 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 REF Right Drive Wheel Assembly (Refer to Page 44) 1
2 53044 SHMS M5 × 10 11
3 42400 Lift Up Limit Switch 1
4 50386 CSCS M06-1.00 × 25 Phillips 2
5 41112 Hydraulic Hoses Manifold 1
6 53051 HHMS M6 × 16 1
7 41372 Electric Bar 1
8 42401 PHP Cover Plate 1
9 42402 Lift Down Limit Switch 1
10 50000 WSHR M06 ZP Standard Flat 3
11 53046 WSHR M6 Spring Washer 3
12 50028 HHCS M06-1.00 × 20 08 ZP F 2
13 42403 Tilt Sensor Plate 1
14 41098 Level Sensor 1
15 53038 WSHR M05 Standard Flat ZP 14
16 53043 WSHR M5 Spring Washer 12
17 53044 SHMS M5 × 10 12
18 42404 Down Limit Switch Seat 1
19 42405 Ladder 1
20 50001 WSHR M08 ZP Standard Flat 4
21 53055 WSHR M8 Spring Washer 4
22 50348 HHCS M08-1.25 × 25 08 ZP F 4
23 41309 Cover 1
24 53038 Nut M5 2
25 53082 SHCS M05-.8 × 35 2
26 41310 Beacon 1
27 42406 Beacon Seat 1
28 42407 Plate 1
29 53026 BHCS M06-1.00 × 12, 10.9, ZP, F 5
30 REF Left Drive Wheel Assembly (Refer to Page 42) 1
31 50034 HHCS M10-1.50 × 30 08 ZP F 8
32 53054 WSHR M10 Spring Washer 8
33 50002 WSHR M10 ZP Standard Flat 8
34 41196
Lock Plate 2
35 REF Pothole Protection Assembly (Refer to Page 38) 1
36 REF Battery Tray Module (Refer to Page 48) 1
37 41794 Screw, Steering Wheels, 1930SE 2
38 41197 Switch, Limit 2
39 53065 SHCS M04 × 30 4
40 41315 Switch Cover 1
41 41792 Seal 2
42 41595 Bearing 4
43 REF Steer Linkage (Refer to Page 40) 1
44 41198 Cover, Switch 1
45 50284 WSHR M04 ZP Standard Flat 4
46 53062 WSHR M4 Spring Washer 4
47 53034 BHCS M04-0.70 × 12 10 ZP 8
48 42408 Chassis Weldment 1
49 41596 Cover 2
REF - Reference
