Page 39 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 41203 Bearing, (PHP Plunger) 4
2 41204 Pressure Head 2
3 41205 Pressure Lever 2
4 41206 Adjusting Washer 2
5 42409 PHP Guard Plate 1
6 50031 HHCS M08-1.25 × 25 08 ZP F 4
7 42410 PHP Guard Plate 1
8 41209 Cross Board Annul (Axle, PHP) 4
9 41210 Bearing, Axle 4
10 50002 WSHR M10 ZP Standard Flat 7
11 50049 NNYL M10 × 1.50 08 ZP Nylon Inse 4
12 41211 Limit, Annul (Pothole Bar) 2
13 41212 Gas Pole Annul (PHP Pivot) 2
14 42411 PHP Linkage Arm 2
15 41214 Bearing (PHP Pivot BNG) 8
16 53049 WSHR M14 Flat 6
17 50303 NNYL M14 × 2.00 10 ZP Nylon Inse 4
18 41215 Gas Spring 2
19 50303 NNYL M14 × 2.00 10 ZP Nylon Inse 2
20 41216 Wheel Annul (PHP Roller Axle) 2
21 53056 HHMS M5 × 12 2
22 41217 Wheel (PHP Roller) 2
23 41319 Mid Linkage Weldment 1
24 50049 NNYL M10 × 1.50 08 ZP Nylon Inse 4
25 41320 Mid Linkage Weldment 1
26 41220 Press Axes Seat (PHP Housing) 1
To Next Page
