Page 41 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 50049 NNYL M10 × 1.50 08 ZP Nylon Nut 2
2 50002 WSHR M10 ZP Standard Flat Washer 2
3 41210 Bearing, Tie Rod Bushing 4
4 42412 Tie Rod 1
5 41222 Washer, Thrust 2
6 41223 Steering Cylinder 1
7 41321 Pin 2
8 41322 Pin 6
9 41225 Bearing, Steer Cylinder 4
10 41226 Washer, Thrust 2
11 42413 Yoke, Left 1
12 42414 Wheel 2
13 41235 Washer, Wheel Shaft 4
14 41236 Nut M16 × 1.5 (Castle Nut) 4
15 41323 Cover Wheel 2
16 50321 Screw 6
17 41230 Shaft End Baffle 2
18 53118 Screw 8
19 41231 Bearing 4
20 42498 Key 2
21 42415 Shaft, Wheel 2
22 41234 Hub, Wheel Connecting 2
23 50033 HHCS M10-1.50 × 25 08 ZP F 12
24 41237 Plate, Shaft End Cover 2
25 50457 Screw 12
26 42416 Yoke, Right 1
