Page 45 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 41239 Support, Motor 1
2 42417 Screw HX-SHCS 3/8-24 × 1.25-N 4
3 53054 WSHR M10 Spring Washer 4
4 50002 WSHR M10 ZP Standard Flat 4
5 42498 Key 1
6 50004 WSHR M16 ZP Standard Flat (Din 125) 1
7 50321 BHCS M04-0.70 × 10 10 BK 3
8 41323 Cover, Wheel 1
9 41236 Nut M16 × 1.5 (Castle Nut) 1
10 42414 Wheel 1
11 42421
Drive Motor (Ground Control Right Side) Assy
1
12 42890 Motor 1
13 42887 Reducer (Gearbox) 1
14 42889 Brake 1
To Next Page
