Page 49 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 42422 Hydraulic Power Unit (Refer to Page 52) 1
- 42423 Valve Body 1
1a 42424 Motor 1
- 42425 Pump 1
- 41245 Lift Valve Solenoid 1
- 41246 Steer Valve Solenoid 1
- 42426 Tank 1
- 42427 Flow Comp Valve 1
2 41413 Joint Nut 1
3 42428 Hose Assembly 1
4 41296 Straight Fitting (Adapter) 3
5 50127 SHCS M10-1.50 × 30 12 ZP F 2
6 53054 WSHR M10 Spring Washer 2
7 50002 WSHR M10 ZP Standard Flat 2
8 41075 Horn 1
9 41074 Alarm 1
10 REF Battery Group 31 AGM 115AH 2
11 42429 Hose Track 1
12 53138 SHCS M06-1.0 × 16, 10 ZP 4
13 53285 HHCS M6 - 1.0 × 20 2
14 53046 WSHR M6 Spring Washer 6
15 50000 WSHR M06 ZP Standard Flat 14
16 42430 Plate, Hose Track 1
17 41331 DC Contactor 1
18 53097 SDFH M05-0.8 × 12MM Phillips 2
19 53043 WSHR M5 Spring Washer 10
20 53038 WSHR M05 Standard Flat ZP 22
21 53042 HHMS M5 × 16 2
22 42431 Mounting Plate, MC1 1
23 42432 Fuse 1
24 53042 HHMS M5 × 16 2
25 42496 Motor Controller 19 1
26 50028 HHCS M06-1.00 × 20 08 ZP F 4
27 41335
Lock 2
28 50028 HHCS M06-1.00 × 20 08 ZP F 8
29 50047 NNYL M06X1.00 08 ZP Nylock 8
30 REF Ground Control Panel Assembly (Refer to Page 50) 1
31 53044 SHMS M5 × 10 6
32 50321 BHCS M04-0.70 × 10 10 BK 2
33 41575 Input Socket 1
34 42433 Battery Box Weldment 1
35 41065 Power Switch 1
36 41254 Charger 1
37 50591 BHCS M05-0.80 × 20 08 ZP F 12
38 41255 Glide Track 2
39 50524 NNYL M05-0.80 12
40 53139 FHSC M10-1.50 × 30 10 F 2
41 41337 Fix Panel 1
42 41092 Fuse Seat 1
43 41672 900W Inverter (Option) 1
REF - Reference
