Page 51 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 41070 Motor Hour Meter 1
2 41422 Emergency Stop 1
3 41421 Indicator 1
4 41614 Brake Reset Switch 1
5 41419 Up-Down Switch 1
6 42434 Panel 1
7 41418 Key Switch 1
- 41668 Key Replacement, Spare AR
8 50321 BHCS M04-0.70 × 10 10 BK 8
9
41889 ECU Modular - From Serial 16900000 - 16900460 1
42435 ECU Modular - From Serial 16900461 - Current 1
10 50284 WSHR M04 ZP Standard Flat 4
11 50285 NNYL M04 × 0.70 08 ZP 4
12 41334 Relay 1
13 94583 Silicone, Smoke Seal (3.5 feet) 1
14 42494 Plastic Edge Trim W/ Metal Core Yellow 22 Inches 1
15 41964 Battery Hold Down Channel 1
16 50047 NNYL M06 × 1.00 08 ZP Nylock 1
17 50214 HHCS M06-1.00 × 30 08 ZP P 1
18 53132 M6 × 25 LG Phillips Round Head 4
19 53133 Nylon 6/6 Plastic (Wing Nut) 4
20 42491 Water Deflector 1
21 8909 Enclosure Service Manual 1
22 50238 NNYL #10-32 05 Z 4
23 50191 THMS #10-32 × 0.50 ZP 4
