Page 53 Micro 19 - Service & Parts Manual
November 2019Section 13 - Chassis
Item Part Number Description Qty.
1 42424 Motor 1
2 43768 O-Ring 1
3 43769 Tang Drive 1
4 43770 Pump Interface 1
5 43771 O-Ring 1
6 43772 Check Valve 1
7 43773 Orifice 1
8 41245 2 Position Valve 1
9 41895 Solenoid 1
10 50001 WSHR M08 Standard Flat 2
11 53055 WSHR M08 Spring Washer 2
12 53301 SHCS M08-1.25 × 90 2
13 43772 Suction Strainer 1
14 43773 Elbow Fitting 1
15 43774 Tube 1
16 43775 Return Tube 1
17 43776 Drain Plug 1
18 43777 Sealing Washer 1
19 41244 Gear Pump 1
20 43778 Manifold 1
21 43779 O-Ring 4
22 43780 Orifice 2
23 43781 Relief Valve 1
24 41894 Solenoid Steer 2
25 41246 Steer Valve Solenoid 1
26 43781 Relief Valve 1
27 43782 Port Plug 16
28 43783 Sealing Washer 16
29 53046 WSHR M06 Spring Washer 3
30 53302 SHCS M06-1.00 × 55 3
31 53303 HHCS M05-0.8 × 8 Flange 4
32 43784 Filler/Breather 1
33 43785 Reservoir 1
