Mec Micro 19 - Page 59

Page 55 Micro 19 - Service & Parts Manual
November 2019Section 14 - Scissor
Item Part Number Description Qty.
1 42437 Circlips For Shaft D25 36
2 41354 Circle, Washer 34
3 41349 Axle 6
4 41576 Axle, Scissor Stack, Upper 1
5 41256 Bottom Slider 2
6 42438 Hose Carrier 2
7 41577 Axle, Scissor Stack, Lower 10
8 50386 CSCS M06-1.00 × 25 Phillips 4
9 53046 WSHR M6 Spring Washer 4
10 50000 WSHR M06 ZP 4
11 42439 Cylinder Pin Fixing Board Plate 2
12 42440 Cylinder Axle 3 1
13 REF Upper Lift Cylinder Assembly (Refer to Page 66) 1
14 42442 Hose Carrier 2
15 41262 Safety Holder 2
16 41263 Safety Arm 2
17 42443 Inner Arm 2 1
18 42444 Inner Arm 1 1
19 50047 NNYL M06 × 1.00 08 ZP Nylock 4
20 42445 Bolt M6 × 55 2
21 42446 Bearing 28
22 41338 Top Slider Axle 2
23 42447 Bottom Slider 2
24 42448 Outer Arm 1 1
25 50386 CSCS M06-1.00 × 25 Phillips 2
26 41350 Pot Hole Pressboard 1
27 50028 HHCS M06-1.00 × 20 08 ZP F 3
28 42449 Pin 4
29 42450 Retainer Base Axle 1
30 41114 Block 32
31 REF Lift Cylinder Assembly (Refer to Page 64) 1
32 41345 Cylinder Axle 2
33 50591 BHCS M05 × 12mm 2
34 41582
Collar 2
35 42452 Inner Arm 3 1
36 42453 Outer Arm 2 6
37 50028 HHCS M06-1.00 × 20 08 ZP F 3
38 42454 Cylinder Axle 2 1
39 42455 Inner Arm 4 1
40 41287 Bearing, Lift Cylinder 64
41 42456 Inner Arm 5 1
42 42457 Axle 1
43 42458 Outer Arm 5 1
REF - Reference
