Page 59 Micro 19 - Service & Parts Manual
November 2019Section 15 - Platform
Item Part Number Description Qty.
1 41279 Platform Guardrail 1
2 41283 Platform Guardrail 1
3 REF Platform Controls (Refer to Page 62) 1
4 53042 PHMS M6 × 16 4
5 41282 Control Box Mount Bracket 1
6 50418 CARB M08-1.25 × 25 08 ZP Carriage 1
7 42500 Fixed Plate 1
8 42501 Star Handle 1
9 53035 BHCS M05-0.80 × 16, G08, ZP 2
10 41120 Rubber Gasket 2
11 53014 NHEX M08-1.25, ZP 12
12 50001 WSHR M08 ZP 12
13 50018 HHCS M08-1.25 × 80 08 ZP P 4
14 41280 Platform Guardrail 1
15 50016 HHCS M08-1.25 × 55 08 ZP P 8
16 41361 Platform Extension 1
17 50001 WSHR M08 ZP Standard Flat 2
18 50030 HHCS M08-1.25 × 20 08 ZP F 2
19 41140 Platform Extension Lock Assembly 1
20 41284 Slide Pad 2
21 53045 HHMS M5 × 14 8
22 53069 CSCS M06 × 20 8
23 41360 Roller Mount 2
24 41141 Roller 2
25 41131 Bearing 2
26 41358 Circlip 2
REF - Reference
